SX95 Stereo Sub woofer Filter
Connection guide
Rolls Corporation
Salt Lake City, UT
9/18
Made in USA
ww.rolls.com
What's in the box?
1 - Made in USA SX95
1 - 15V power supply PN PS27s
1 - This owners manual
Made in USA
ww.rolls.com
SPECIFICATIONS:
Input Impedance: 10K Ohm
Output Impedance: 1K Ohm
Headroom: +10 dBV
Power Requirements: 12 - 15 VDC, 500 mA;
Rolls part number PS27s
Size: 4” x 4.5” x 1.5”
Weight: 1 lb.
• 12 dB/Octave roll o
• Stereo RCA Input and Outputs
• 36Hz to 200 Hz crossover range
• Mono or Stereo Sub Output
Connect the SX95 to the output of
a preamplier, mixer or other device
containing a stereo signal. This sig-
nal should be Line-Level, or refer-
ence 0 to +4 dB.
Set your ampliers to their normal
operating level (many ampliers are
simply set at their full volume level).
Carefully begin increasing the SX95
Level control until you reach a de-
sired volume level.
Adjust the Sub Frequency to the de-
sired level for your sub woofers. We
recommend selecting the 0 degrees
phase setting on both channels to
start, then make your adjustments
later as needed.
The Rolls SX95 is a true stereo sub
woofer crossover. It also features a mono
or stereo selection switch to utilize the
SX95 in mono. The SX95 features a true
pass thru output that will allow proper
connection to your system without any al-
terations to the original signal. The SX95
is a perfect way to separate low frequen-
cies from line level program material in
any system, home, professional or an
installation. With a frequency range of
36Hz to 200Hz, and an external power
supply for noise reduction the SX95 will
allow you to have complete control of you
subs.
CONNECTION:
DESCRIPTION:
