Side 1/7
BTC-2X
Bluetooth Remote Transceiver
INSTALLATION GUIDE
BTC-2X
TO BTC-2 or MCA
POWER
PAIR
AUDIO
OUT
REMOTE PAIR
5V 2A
2
Russound BTC-2X Installation Guide
Russound BTC-2X Installation Guide
3
USING YOUR BTC-2X AS A STANDALONE BLUETOOTH AUDIO CONNECTION
The BTC-2X can be used to easily provide Bluetooth audio from a phone or tablet to any audio system.
AUDIO CONNECTION
The BTC-2X can be connected to any audio device using its 3.5mm stereo output connection. Depending on the
input of your audio device, use either a 3.5mm to 3.5mm cable or a 3.5mm to stereo RCA cable to connect the BTC-
2X (cables not included).
POWER CONNECTION
Use the included MicroUSB power cable and the included 5VDC power supply to supply power to the BTC-2X.
Your BTC-2X includes adaptor plates for US, UK, Euro, and AUS power sockets. To change the adaptor, simply press
the button marked βPushβ to release the plate and, after aligning the new adaptor plate properly, simply snap it into
place until it clicks.
PAIRING MODE
The BTC-2X has two pairing modes: automatic and manual, which are set via a convenient slide switch on the
bottom of the BTC-2X.
Automatic Pairing
Automatic Pairing is the simplest method and is designed for use in most residential single-family homes or any
environment where it is not likely to have any neighbors or other people close enough to pair their phones or tablets
to the BTC-2X. When not connected to a phone or tablet, the BTC-2X will always be available to pair with any new
device within range that requests pairing.
OVERVIEW
OPERATION
Thank you for purchasing the BTC-2X Bluetooth Remote Transceiver from Russound. Since 1967, Russound has been
providing audio professionals with the tools they need to enhance the lives of their customers. The BTC-2X can be
used in multiple ways:
β’ As a standalone Bluetooth receiver
β’ As a remote Bluetooth receiver with Russoundβs MCA-66 and MCA-88 controllers
β’ As part of the BSK-2 Bluetooth Source Kit to provide multiple Bluetooth inputs to a Russound controller in the
same installation
β’ As part of the BSK-2 Bluetooth Source Kit to allow the Bluetooth radio to be located up to 500β (152m) from
connected audio gear, allowing for the ultimate in Bluetooth range in any home or business.
With its advanced Bluetooth 5.1 technology, the BTC-2X is the perfect solution for your Bluetooth audio needs
GETTING TO KNOW YOUR BTC-2X
BTC-2X
TO BTC-2 or MCA
POWER
PAIR
AUDIO
OUT
REMOTE PAIR
5V 2A
ξξξξξξξξξξξξξξξξξξ
ξξξξξξξξξξξξ ξ
ξξξξξξξξξξξξ: ξξξξξξξξξξ
ξξξξξξξξξξξξξ
ξξξξξξξξξξξξ
ξξξ
ξξξξξξ
ξξξξ
ξξξξξξΏξξξξ
ξξξξξξξξξξξξ
ξ
ξ
ξ
ξ
ξ
ξ
ξ
ξ
ξξξξξξξξξ
ξξξξξξ
Serial
Number
MAC ID
MicroUSB Power
Connection
Source Number Switch (Only used
when connected to a Russound
MCA-Series Controller)
Connect to
MCA-Series
Controller
Pairing Button
3.5mm Stereo
Audio Out
Pairing Mode
Switch
MAC ID Label
Keyhole Mounting
Slots
Remote Pairing
Contact Closure
4
Russound BTC-2X Installation Guide
Russound BTC-2X Installation Guide
5
Manual Pairing
Manual Pairing is designed for all applications when greater control over the Bluetooth connections is desired and
especially in environments where multiple homes are within Bluetooth range such as Multi-Dwelling Units (MDUβs) like
condominiums, townhouses, apartments, etc.
When in manual pairing mode, the BTC-2X will only be able to pair with new phones or tablets when not connected to
a device and someone:
a) Presses the βPairβ button on the rear panel of the BTC-2X; - OR -
b) Activates the βRemote Pairβ contact closure on the rear panel of the BTC-2X. The Remote Pair is a unique
optional feature that allows an installation professional to wire a simple push button control or to use an
automated contact closure from a smart home control system. This allows the BTC-2X to be hidden completely
from sight and still be able to be put into pairing mode easily when desired.
NAMING YOUR BTC-2X
A convenient feature of the BTC-2X is the ability to re-name it to a βfriendlyβ name that makes it easier to access and
use in your home. The default name of the BTC-2X is βBTC-2X-ZZZZβ with βZZZZβ being the last four digits of the
deviceβs MAC ID.
After installing your BTC-2X using one of the configuration options listed below, you can easily rename it to something
more convenient. For example, if you install the BTC-2X in your Living Room, you can rename it to βLiving Roomβ so
that it is easier to identify on your phone or tabletβs list of available Bluetooth devices.
TO RENAME YOUR BTC-2X
1) Download and install the Russound BTC-2X Naming App from either the App Store or the Google Play Store.
2) With the BTC-2X powered up, within Bluetooth range, and already paired to your phone, open the BTC-2X
Naming App.
3) The app should automatically discover all Russound BTC-2X devices within range. You can refresh the screen by
swiping down in the app.
4) Once your BTC-2X is discovered, select it and tap βConnectβ. Once connected, you can enter a new Bluetooth
name and tap βEnterβ.
5) Your BTC-2X has now been configured with the new name.
Note: Names can be up to 15 characters long and composed of any mix of letters from A-Z, Numbers 0-9 and the β-β
character. To avoid confusion, we recommend using a diξerent name from all other Bluetooth devices in the home.
USING YOUR BTC-2X WITH A RUSSOUND MCA-SERIES CONTROLLER
The BTC-2X is the perfect companion Bluetooth audio solution for a Russound MCA-66 or MCA-88 audio controller.
The Russound controller has an RJ-45 port on the rear panel that is used to connect a CAT5 cable to the BTC-2X. The
CAT5 cable is used to carry power, data, and high quality audio signals between the two devices.
The BTC-2X can then be located up to 500β (152m) away from the MCA-Series controller and placed exactly where it
needs to be in the home to provide the strongest Bluetooth signal. With its elegant design, the BTC-2X can be placed
on a shelf, or it can be hidden from sight and mounted to a wall or inside a cabinet using the convenient keyhole
mounting slots. If hiding the BTC-2X, we recommend using Automatic Pairing Mode. If that is not possible, the BTC-
2X can be placed in Manual Pairing Mode and a remote button can be installed that uses the Remote Pair contact
closure to activate pairing whenever desired.
SETTING THE SOURCE NUMBER
Before using the BTC-2X with a Russound MCA-66 or MCA-88, the source number switch on the bottom of the BTC-
2X must be properly set to the same source number that is configured in the MCA-Series controllerβs WebConfig.
SET SOURCE NUMBER ON THE BTC-2X AND THE MCA-SERIES CONTROLLER TO SOURCE 1
By default, the RJ-45 Bluetooth connection on the MCA-Series controller is set to Source 1. The BTC-2X default source
number is also set to Source 1 so that it will normally work as a plug and play installation with no extra configuration
needed. Make sure that the MCA-Series controllerβs Source 1 is configured with the Source Type of βBTC-2Xβ.
OPERATION USING WITH A MCA-SERIES CONTROLLER
