User Guide

HW-S80*D / HW-S81*D / HW-S81*GD

HW-S70*D / HW-S71*D / HW-S71*GD

Thank you for purchasing this Samsung product.

To receive more complete service, please register your product at

www.samsung.com

Figures and illustrations in this User Guide are provided for reference

only and may differ from actual product appearance.

ENG - 2

CONTENTS

01 Checking the Components 3

02 Product Overview 4

Top Panel of the Soundbar. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Rear Panel of the Soundbar. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

03 Using the Soundbar Remote Control 6

How to Use the Remote Control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Setting the

(Sound Control). . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Using the Hidden Buttons (Buttons with more than one

function). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Output specications for the different sound effect modes. . . . 9

Adjusting the Soundbar volume with a TV remote control . . . . 10

04 Connecting the Soundbar 11

Connecting the power and units . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

‒ Manually connecting the Subwoofer . . . . . . . . . . . . . . . . . . . . 12

‒ LED Indicator Lights on the Rear of Subwoofer . . . . . . . . . . . 13

Connecting an Samsung Wireless Rear Speaker Kit (Sold

Separately) to your Soundbar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

05 Connecting to a TV 14

Connecting the TV that supports HDMI ARC (Audio Return

Channel) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Connecting via Bluetooth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Connecting via Wi-Fi . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Connecting to a TV that supports Dolby Atmos . . . . . . . . . . . . . . 17

Using the Q-Symphony Function . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Using the Spacet sound . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

06 Connecting a Mobile Device 20

Method 1. Connecting via Bluetooth . . . . . . . . . . . . . . . . . . . . . . . .20

Method 2. Connecting via Wi-Fi (Wireless Network). . . . . . . . . . 22

Using Group Play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Connecting via Apple AirPlay . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

Using the Tap Sound . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

07 Installing the Wall Mount 24

Installation Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Wallmount Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

08 Installing the Soundbar in front of TV 25

09 Software Update 26

Auto Update . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26

USB Update . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26

Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Security updates information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

10 Troubleshooting 27

11 License 28

ENG - 3

01 CHECKING THE COMPONENTS

SOUNDBAR

Soundbar Main Unit / Subwoofer Soundbar Remote Control

(HW-S80*D / HW-S81*D / HW-S81*GD)

Soundbar Remote Control

(HW-S70*D / HW-S71*D / HW-S71*GD)

/Batteries

x 2

AC/DC Adapter (Soundbar) Power Cord (Subwoofer, Soundbar) HDMI to Micro HDMI Cable

AH81-15127A-01

A TYPE

***mm

B TYPE

***mm

x 2

Wall Mount Guide Bracket-Wall Mount Holder-Screw

x 4

(M5 X L55)

x 4

Screw Screw Anchor

• For more information about the power supply and power consumption, refer to the label attached to the product.

(Label: Rear of the Soundbar Main Unit)

• To purchase additional components or optional cables, contact a Samsung Service Center or Samsung Customer Care.

• For more information about the wallmount or rubber-foot, see pages 24~25.

• Design, specications, and App screen are subject to change without prior notice.

• The appearance of the accessories may differ slightly from the illustrations above.

Produkspesifikasjoner

Merke:	Samsung
Kategori:	lydrekke
Modell:	HW-S711GD
Bredde:	890 mm
Dybde:	39.9 mm
Høyde:	38 mm
Bluetooth:	Ja
Wi-Fi:	Ja
Bluetooth-versjon:	5.2
Tilkoblingsteknologi:	Ledning & Trådløs
Pakkevekt:	9200 g
Antall høyttalere:	7
Nattmodus:	Ja
Apple AirPlay 2-støtte:	Ja
Spillmodus:	Ja
Spotify Connect:	Ja
Strømforbruk (standby):	0.5 W
Støttede lydformater:	AAC, AIFF, ALAC, FLAC, MP3, OGG, WAV
Produktfarge:	Hvit
Pakkedybde:	443 mm
Pakkehøyde:	272 mm
Pakkebredde:	967 mm
Strømforbruk (vanlig bruk):	54 W
Fjernkontroll medfølger:	Ja
Kan monteres på vegg:	Ja
Subwoofer inkludert:	Ja
Subwoofer-vekt:	5900 g
Lyd-utgang kanaler:	3.1 kanaler
RMS-rangert strøm/utgangseffekt:	250 W
Utjevner/frekvenskorrigerer:	Ja
Innebygd lyddekoder:	Dolby Atmos, Dolby Digital 5.1, Dolby TrueHD
Veggmonterings sett:	Ja
Subwoofer RMS-styrke:	160 W
Lydplankens RMS-effekt:	- W
Subwoofer-tilkoblingsevne:	Trådløs
Lydplankevekt:	840 g
Bredde subwoofer:	205 mm
Dybde subwoofer:	302 mm
Høyde subwoofer:	353 mm
Lydplankens strømforbruk:	28 W
Equalizer-moduser:	Adaptive, Game Pro, Standard, Surround Sound Expansion
Samsung-teknologier (AV/TV):	Adaptive Sound
Q-Symphony:	Ja
Strømforbruk subwoofer:	26 W
