Side 1/4
KIRAY 300
Infrared thermometer
USER MANUAL
Spectral response 8 - 14 μm
Optical D.S: 50:1 (50.8 mm at 2540 mm)
Temperature range From -50 to +1850 °C
Accuracy*
From -50 to +20 °C: ±3 °C
From +20 to +500 °C: ±1% ±1 °C
From +500 to +1000 °C: ±1.5%
From +1000 to +1850 °C: ±2%
Infrared repeatability
From -50 to +20 °C: ±1.5 °C
From +20 to +1000 °C: ±0.5% or ±0.5 °C
From +1000 to +1850 °C: ±1%
Display resolution 0.1 °C
Response time 150 ms
Emissivity Adjustable from 0.10 to 1.00 (pre-set at 0.95)
Over range indication Display indication: "----"
Dual laser sighting
Wavelength: from 630 nm to 670 nm
Output < 1mW, Class 2 (II)
Positive or negative
temperature indication
Automatic (no indication for a positive temperature)
(-) sign for a negative temperature
Display 3 lines, 4 digits with backlighted display LCD
Auto-extinction Automatic after 7 seconds of inactivity
High/low alarm
Flashing signal on display and beep signal with
adjustable thresholds
Power supply Alkaline 9 V battery
Autonomy
95 h (inactive laser and backlight)
15 h (active laser and backlight)
Operating temperature
From 0 to +10 °C for a short period
From 11 to +50 °C for a long period
Storage temperature From -10 °C to +60 °C
Relative humidity From 10% to 90%RH in operating mode and >80%RH in storage
Dimensions 200 x 140 x 50 mm
Weight 320 g (included battery)
Memory 100 temperature values
*Accuracy for an ambient temperature from 23 to 25 °C (with a relative humidity lower than 80% RH).
Infrared thermometer Kiray 300 is a thermometer used to diagnose, inspect
and check any temperature. Thanks to its elaborated optical system with a dual
laser sighting, it allows easy and accurate measurements of little distant targets.
The KIRAY 300 instrument has an internal memory which can save up to 100
measurements. Compatible with thermocouple K probe.
Technical specications
°C
°F
Distance from the target
Please make sure that the target is larger than
the size of the laser sighting.
Thermocouple K probe features
Temperature range From -40 to +400 °C
Display range From -50 to +1370 °C
Resolution 0.1 °C
Accuracy ±1.5% of reading ±3 °C
Cable length 1 m
Supplied with
thermocouple K
probe
