Side 1/21
SCOTT BACK PROTECTOR
USER MANUAL
• DESIGNATION OF THE PRODUCTS & SIZE CHART
SCOTT AIRFLEX MEN’S LIGHT VEST PROTECTOR | B2002_01
SCOTT AIRFLEX MEN’S POLAR VEST PROTECTOR | B2002_03
S M L XL
35-40 cm 39-44 cm 42-47 cm 44-49 cm
SCOTT AIRFLEX BACK PROTECTOR | B2002_06
XS S M L XL
35-40 cm 35-40 cm 39-44 cm 42-47 cm 44-49 cm
SCOTT AIRFLEX PLATE | B2002_09
XXS XS S / S-E M / M-E / L-E XL-E
28-3 cm 31-35 cm 35-40 cm 39-44 cm 42-47 cm
SCOTT AIRFLEX PRO MEN’S VEST PROTECTOR | B2001_01
S M L XL
39-44 cm 39-44 cm 42-47 cm 44-49 cm
SCOTT VANGUARD EVO VEST PROTECTOR | B2002_08
S M L XL
35-40 cm 39-44 cm 39-44 cm 42-47 cm
SCOTT AIRFLEX PRO BACK PROTECTOR | B2001_02
S/M L / XL XL / 2XL
39-44 cm 42-47 cm 44-49 cm
SCOTT AIRFLEX WOMEN’S LIGHT VEST PROTECTOR | B2002_02
SCOTT AIRFLEX WOMEN’S POLAR VEST PROTECTOR | B2002_04
S M L XL
35-40 cm 35-40 cm 39-44 cm 42-47 cm
SCOTT AIRFLEX JUNIOR VEST PROTECTOR | B2002_05
SCOTT AIRFLEX JUNIOR BACK PROTECTOR | B2002_07
XXS XS S M
28-31 cm 31-35 cm 35-40 cm 39-44 cm
SCOTT RENTAL ACTIVE BACK PROTECTOR | B2002_14
XXS XS S M L XL
31-35 cm 35-40 cm 35-40 cm 39-44 cm 42-47 cm 44-49 cm
SCOTT RENTAL ULTIMATE MEN’S VEST PROTECTOR | B2002_15
S M L XL
35-40 cm 39-44 cm 42-47 cm 44-49 cm
SCOTT RENTAL ULTIMATE WOMEN’S VEST PROTECTOR | B2002_16
S M L XL
35-40 cm 35-40 cm 39-44 cm 42-47 cm
CONTENTS
ENGLISH 4
DEUTSCH 9
FRANÇAIS 14
ESPAÑOL 19
ITALIANO 24
SVENSKA 29
DANSK 34
Torso length
Länge des Rückens
Longueur du dos
Longitud del torso
Lunghezza torso
Torso-lengde
Torso længde
ENGLISH - 4 5 - ENGLISH
• I. INTRODUCTION
Congratulations on choosing this quality SCOTT product. Before use, please read the following
instructions carefully and keep these instructions in safe custody. This specific product line has
been developed to offer you the best comfort and fit.
SCOTT Sports SA shall not accept any complaints arising from using the product for other pur
-
poses than that indicated in the present information notice, nor shall they be liable for any dam-
ages and / or losses.
• II. LEGAL REQUIREMENTS
This SCOTT product is considered to be an item of Personal Protective Equipment (PPE) of Catego-
ry II and as such is subject to the requirements laid down by the Regulation (EU) 2016 / 425.
RELEVANT STANDARDS
This product meets the testing and technical requirements set out by the standard EN 1621-
2 : 2014 (please refer to the labelling inside the product).
• III. INTENDED USE AND LIMITATIONS
This SCOTT product is strictly limited for the respective use indicated by the pictograms on the certi-
fied label on the product (see chapter IV. Product Information). The protector is not to be used above
or below indicated temperatures, nor for other kinds of sports. The intended and reasonably foresee
-
able use of this product is solely : wintersports, off-road motosports or bike.
A. RISK AGAINST WHICH THE PPE IS SUPPOSED TO PROTECT
This SCOTT product is designed and manufactured to provide limited protection against the
risk of shock in the event of a fall. The product does not safeguard against other traumas or
extreme movements. This product provides limited protection only in the areas covered by the
equipment. The product can arch both forward and backward to simulate and support natu
-
ral movement. These movements prevent the direct transmission of forces to the edge of the
protector. This SCOTT product does not safeguard against traumas caused by twisting, tor
-
sion or extreme movements.
B. LEVEL OF PROTECTION
These SCOTT Products have been designed within the requirements of the European safety
standard EN 1621-2 : 2014 “Motocyclist’s protective clothing against mechanical impact - Part 2 :
Motorcyclists’ back protector - Requirements and tests method”. The back protectors have been
examined and certified according to EN 1621-2 : 2014 and have been classified as type FB (= Full
Back), level 1 or 2 ( Please ref. to point
&
chapter IV).
C. PERFORMANCE RECORDED
In addition to the standard conditioning provided by the norm, certain of our protectors have
been subjected to temperature conditioning before impact tests in order to prove their perfor
-
mance under cold and warm temperatures, please ref. to point
&
chapter IV.
D. MISUSES
Bending or twisting the protector excessively is considered improper use and it may cause the
loss of protective properties or damage the equipment.
Changes in environmental conditions such as temperature and wetness could significantly
reduce the performance of the protector. Never tamper with any part of the protectors. Do not
paint the protector nor use colorants of any nature.
During use, the protector’s temperature must not drop below -10 °C.
We recommend that the SCOTT product should not be left outside, exposed to low tempera
-
tures or direct sunlight before use. Any product modifications may cause loss of protection and
are therefore considered as improper use.
• IV. PRODUCT INFORMATION
A. MARKING ON THE PRODUCTS
The labels are stitched into the SCOTT product.
EN 1621-2:2014
XX-XX
XXXXXX
XXXXXX
S
AA.16.01.1234567.XXXXXX
…
B. EXPLANATION OF MARKINGS
Model identification
Commercial name
Torso length : measured on the back from the waist line to the junction of the shoulder
to the neck at the highest point
Icons indicate the specific sport for which the protector is designed to be used :
wintersports, o-road motosports or bike.
BACK PROTECTOR
FB Full Back / CB Central Back / LB Lower Back Protector : Zone of protection
1 / 2 : Level of protection
T+ : High temperature impact test passed
T- : Low temperature impact test passed
EN 1621-2 : 2014 : Standard for Personal Protective Equipment that is in compliance with the
European technical standard used in the design and EU certification
Protector size and additional body measurements and fit
Warning ! The end user should carefully read the instruction before using
the product (PPE)
The CE marking ensures compliance with the essential requirements
of Regulation (EU) 2016 / 425
Manufacturing date : Year-Month / Individual serial number
Article code
SCOTT BACK PROTECTOR
