USER MANUAL
ENGLISH
Outdoor Portable Toilet
with Carrying Bag,Travel Toilet with Level lndicator
SLCAT360
2 www.serenelifehome.com
Introduction
The portable toilet provides simple operation and convenient disposal of waste. Before using your
portable toilet, we recommend that you read this manual completely. Become familiar with your
portable toilet and its components parts. As with any quality product, proper use and operation
eliminates unnecessary maintenance.
Features:
• High-Density Polyethylene Construction
• Built-in Carry Handles for EasyTransport
• Well-Constructed Adult Sized Seat and Lid
• Completely Self-Contained
• No External Water or Power Connections Needed
• Attractive Matte Finish Conceals Marks and Allows Scrubbing without Damage
• Double Sealed Drain Valve Protects Against Leakage and Odor
• Heavy-Duty, Corrosion Resistant Side Latches Lock Tanks Together
• Detached Waste Holding Tank is Easy to Empty
• Enhanced T-type 3 Directional Flush Nozzle Guaranties a Full Bowl Coverage
• Waste Level Indicator tells when to Empty
• Non-Splash Rotating Empty Spout
• Durable carry bag for easy transport & storage
• Useful Toilet Hand Sprayer helps to clean toilet, more hygienic
What's in the Box:
• Portable Toilet
• Oxford Carrying Bag
• Toilet Hand Sprayer
Technical Specs:
• Waste Holding Tank Capacity: 5.8 Gallon
• Fresh Water Tank Capacity: 3.2 Gallon, up to 100 Flushes
• Flush Pump Type: Piston Pump
• EmptyType: Rotating No-Splash Pour Spout
• Construction Material: High-Density Polyethylene
• Product Dimensions (L x W x H): 16.S"x 14.6"x 17.1" -inches
Parts Listing:
Description
Seat Cover
Seat
Cap, Fresh Water Holding Tank
Fresh Water Holding Tank Assembly
Piston Pump Assembly
Side Latch Assembly
Rotating Empty Spout
Waste Holding Tank: 22L
Level Indicator
Slide Valve Assembly
Vent Button
Part No.No.
www.serenelifehome.com 3
Safety Instructions
1. Handle with care.
2. Avoid exposure to direct sunlight for extended periods of time.
3. To avoid injury, DO NOT lean against lid when being used.
4. Ensure waste tank is cleaned regularly.
Maintenance
1. Lubricate Slide Valve seals periodically with silicone spray or white grease lubricant.
2. Clean exterior of toilet with a mild, non-abrasive bathroom cleaner.
Operation/How to use:
1. Fill upper water tank with clean water (Fig.1)
2. Pull out slide valve handle before use. (Fig. 2)
3. Caution: Always press the vent button to release air pressure inside the waste holding tank to
avoid waste spills before opening the slide valve.
4. 3. Flush the toilets by depressing piston pump up and down 2 or 3 times. (Fig. 3)
5. 4. After ush, push the handle back in. (Fig. 4)
To empty holding tank:
1. Empty the waste holding tank when the level indicator turns from green to red. (Fig.S)
2. Make sure the slide valve is closed and separate two tanks by disengaging side latches. (Fig.6)
3. Carry holding tank to permanent toilet facility. (Fig.7)
4. Remove the cap of rotating empty spout.
5. Empty contents into permanent toilet (*Press the vent button to avoid splash) (Fig.8)
6. Rinse tank thoroughly. Reassemble unit and prepare for next use.
Storage:
To store Portable Toilet when not in use:
1. Empty the top tank and waste holding tank.
2. Make sure all water is cleared from the ush pump by depressing pump several times.
3. Stored away from direct sunlight.
Note: A small amount of water may remain in the top tank but will be harmless during storage.
