Side 1/18
USER MANUAL
ENGLISH
Gravity Flush ToiletHigh Prole
with Foot Pedal Operation, T-Type Water Outlets
SLCATL420
2 www.serenelifehome.com
½ Inch Water Inlet
Ø10mm mounng hole
Floor mounng kit
1.Components
Toilet Seat
T Flush Nozzle
Toilet Base
Toilet Pedal
Toilet Pedalzzz
Toilet Lid
T-bolt and
rubber case
Flange plate Seal ring
Gravity Flush Toilet User Manual
Main Features:
• Premium user comfort. Full size &
soft-close seat and lid, large toilet bowl
and478mm seat height brings greater
homelike performance.
• Easy to ush. High gloss toilet bowl
with original T type 3 way ush
owcreates high-speed, full bowl
ushing.
• Ergonomically enhanced pedal
operation. Lower pedal height for
easier use.One-direction action to open
drain valve and ush.
• Easy installation. Two bolts design ts
most existing toilet oor anges,
greatfor new or replacement
installation. Just place on oor ange,
tighten boltsconnect water and it’s
ready.
www.serenelifehome.com 3
I
J
K
L
M
!
N
?
O
G
P
C
Ref. Descripon
A 390mm / 15.4”
B 500mm / 19.7”
C 233mm / 9.2”
D 485mm / 19.1”
E 380mm / 15.0”
F 890mm / 35.0”
Ref. Descripon
G Minimum: 200mm / 7.9”
H Minimum: 200mm / 7.9”
I Minimum: 200mm / 7.9”
J 170mm / 6.7”
K 102mm / 4.0”
L 210mm / 8.5”
The outside diameter of the toilet drain outlet: 95mm / 3.7”;
The inner diameter of the toilet drain outlet: 87mm / 3.4”
2.Product and mounting dimension:
3.Installation
Note:
• Be sure foot pedal, when pressed, touches same at surface on which toilet is installed.
• Ensure water supply pressure is no more than 0.4Mpa.
• Hot water more than 40 degrees is forbidden.
1. To replace an older toilet, turn o water supply to toilet. Remove and drain water
supply line. Remove toilet hold-down bolts/screws. Remove toilet from oor. Remove
and discard old ange seal and hold-down bolts. Verify center of oor ange is at least
200mm/7.9” from back wall(Fig.1).
2. If installing a new oor ange, make certain that toilet mounting holes are located at
the correct angle (Fig.1). Floor ange must be secured to oor with a minimum of four
screws. Insert two supplied T-bolts into slots in oor ange(Fig.2).
3. 3)Verify that oor ange seal is installed on base of toilet. Carefully set toilet over oor
ange. Align holes in toilet base with T-bolts as toilet is lowered onto oor ange.
4. Install oor mounting nuts onto T-bolts. When tight, base should be securely attached
and at against oor. Attach bolt covers onto nuts
5. Connect water supply line to ½ inch water inlet and turn on water supply line. (Fig.3)-
Flush toilet several times and check for leaks.
