FX Drop V1
Highlite International B.V. Vestastraat 2 6468 EX Kerkrade the Netherlands
Order code: 61040
MANUAL
ENGLISH
1
Order code: 61040
FX Drop
Table of contents
Warning ............................................................................................................................................................................... 2
Safety Instructions ......................................................................................................................................................... 2
Operating Determinations .......................................................................................................................................... 3
Rigging ............................................................................................................................................................................ 4
Connection with the Mains ......................................................................................................................................... 4
Return Procedure .......................................................................................................................................................... 5
Claims .............................................................................................................................................................................. 5
Description of the Device ................................................................................................................................................ 6
Front View ....................................................................................................................................................................... 6
Back View ....................................................................................................................................................................... 7
Installation ........................................................................................................................................................................... 8
Multiple Fixtures Power Linking ................................................................................................................................... 8
Setup with One FX Drop .............................................................................................................................................. 8
Setup with Multiple FX Drops ....................................................................................................................................... 9
Suspending Objects ...................................................................................................................................................10
Operation ..........................................................................................................................................................................11
Without a Switch Pack ...............................................................................................................................................11
With a Switch Pack .....................................................................................................................................................11
Releasing Suspended Objects Manually ...............................................................................................................11
Maintenance ....................................................................................................................................................................11
Troubleshooting ...............................................................................................................................................................11
Product Specifications ....................................................................................................................................................12
Dimensions ........................................................................................................................................................................13
2
Order code: 61040
FX Drop
Warning
Unpacking Instructions
Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure
that all parts are present, and have been received in good condition. Notify the dealer immediately and
retain packing material for inspection if any parts appear damaged from shipping or the carton itself
shows signs of mishandling. Save the carton and all packing materials. In the event that a fixture must be
returned to the factory, it is important that the fixture will be returned in the original factory box and
packing.
Your shipment includes:
Showtec FX Drop
User manual
Safety Instructions
Every person involved with the installation, operation and maintenance of this device has to:
be qualified
follow the instructions of this manual
Before the initial start-up, please make sure that there is no damage caused by transportation. Should
there be any, consult your dealer and do not use the device.
To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to
follow the safety instructions and warning notes contained in this manual.
Please consider that damages caused by manual modifications to the device are not subject to
warranty.
This device contains no user-serviceable parts. Refer servicing to qualified technicians only.
