Quick Start Guide

You Should Have

The following items should be included in your product package:

• One Solo10G SFP+ PCIe Card

• One additional mounting bracket

• 10GBASE-SR (short-range) SFP+ transceiver

• QSG

The following items may be required for installation:

• Medium Phillips screwdriver

Computer Compatibility

• Mac Pro

(Mid 2010 or newer), PC desktop, or server with full-

height or low-proﬁle PCIe slots

OS Compatibility

• macOS

10.13.6+ (macOS Big Sur compatible)

• Windows

10, 8, 7; Server 2016, 2012, 2008

• Linux

Thunderbolt™ Compatibility

• Mac (Intel

or M1) via a Thunderbolt-to-PCIe card expansion system

• Windows computer running Windows 10 Build 1809 or newer (64-

bit edition) via a Thunderbolt-to-PCIe card expansion system

4. Close your computer or expansion system, and then reconnect

it to its power source. If the card is installed in an expansion

system, also connect the Thunderbolt cable between the

Thunderbolt ports on the system and computer.

5. Insert the included 10GBASE-SR transceiver into the card’s SFP+

socket.

6. Connect a cable between the transceiver in the Sonnet card and

in the switch or device.

Driver Information

For Mac users, the drivers that enable the Solo10G SFP+ PCIe Card

to work in your computer or Thunderbolt expansion chassis are

installed as part of macOS 10.13.6 and later; the Sonnet card is ready

for use when you power on your computer.

For Windows users, please go to www.sonnettech.com/support/kb/

kb.php, navigate to and click the Solo10G SFP+ PCIe Card link.

Click the Driver link and then locate, download, and install the

appropriate drivers.

For Linux users, the drivers that enable the Solo10G SFP+ card to work

with Linux are installed as part of the Linux Kernel 5.0 and later.

For earlier versions, please go to www.sonnettech.com/support/

kb/kb.php, navigate to and click the Solo10G SFP+ PCIe Card link.

Click the Driver link and then locate, download, and install the

appropriate drivers.

Installation Preparation

Sonnet strongly recommends that you read the section in your

computer’s user manual that addresses PCI card installation, prior to

installing the Solo10G card into your system.

Card and Transceiver Installation Steps

1. Shut down your computer or Thunderbolt-to-PCIe card

expansion system and disconnect it from its power source, and

then open it to access the expansion card area (PCIe slots); refer

to the user’s manual for speciﬁc information.

2. Locate an available x4 (4-lane) or larger PCI Express slot and

then remove its access cover.

3. Remove the Sonnet card from its packaging, and then install it

into the PCI Express slot; make sure the card is firmly seated

and secured.

Solo

™

SFP+ PCIe

Card

10 Gigabit Ethernet PCIe

3.0 Adapter Card

With 10GBASE-SR (Short-Range) SFP+ Transceiver

are trademarks of Sonnet Technologies, Inc. Mac, the Mac logo, Mac Pro, and macOS are trademarks of Apple Inc., registered in the

United States and other countries. Thunderbolt and the Thunderbolt logo are trademarks of Intel Corporation in the U.S. and/or other

countries. Other product names are trademarks of their respective owners. Product specifications subject to change without notice.

QS-G10E-SFP-1X-E3-E-F-022421

Support Note: When handling computer products, you

must take care to prevent components from being damaged

by static electricity. Before opening your computer or removing

parts from their packages, always ground yourself first by touching

a metal part of the computer, such as a port access cover, and work

in an area free of static electricity; avoid carpeted areas. Handle all

electronic components by their edges, and avoid touching connector

traces and component pins.

Support Note: When installing the Solo10G card into your

computer, it may be necessary to change the PCIe card bracket

attached to the card with the spare bracket included in the package.

Produkspesifikasjoner

Merke:	Sonnet
Kategori:	Nettverkskort/adapter
Modell:	G10E-SFP-1X-E3
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Kablingsteknologi:	10/100BaseT(X)
Vertsgrensesnitt:	PCI Express
Maksimal dataoverføringshastighet:	10000 Mbit/s
Komponent for:	PC
Fiberoptisk kontakt:	SFP+
Ethernet LAN dataoverføringshastigheter:	1000,2500,5000,10000 Mbit/s
Støttede Windows operativsystemer:	Ja
Ethernet/bredbåndsforbindelse:	Ja
Ethernet-grensesnittype:	10 Gigabit Ethernet, Gigabit Ethernet
Videoopptaksgrensesnitt:	Fiber
Intern:	Ja
Støttede Mac operativsystemer:	Ja
Støttede Linux operativsystemer:	Ja
Fibre Channel-porter:	1
