01 EN EN 02

Charging

• Slide to open or close the charging case to activate the LED battery indicator.

• Fully charge both the earbuds and the charging case before the rst-time using.

• To preserve battery lifespan, fully charge at least once every 45 days.

• To prevent damage, use the provided USB-C cable.

• You can charge the charging case by using a certied wireless charger (not provided).

• Fully dry off the earbuds and the USB port before charging.

< 30%

30% - 70%

> 70%

100%

Powering On/Off

Slide to open the charging case, the earbuds will automatically power on.

Place the earbuds back into the charging case and close the case, the earbuds will

automatically power off.

OFF

LED behavior (Earbuds)

ON Steady white for 1 second

OFF Steady red for 1 second

• To manually power on, press and hold the multi-function button on either one of earbuds

for 1 second.

• To manually power off, press and hold the multi-function button on either one of earbuds

for 5 seconds.

Pairing

True Wireless Stereo Connection

Slide to open the charging case, the earbuds will automatically power on. The right earbud will

automatically connect with the left earbud.

LED behavior (Earbuds)

Breathing white TWS connecting

Steady white for 1 second TWS connected

• When powered off, press and hold the multi-function button on both earbuds for 1

second, the earbuds will enter TWS connecting mode.

• When powered on and connected, place either one of the earbuds into the charging case

and close the case, you can keep using the other one.

• When powered on and connected, if either one of the earbuds is out of battery and

powered off, you can keep using the other one.

• When you are on a call, place either one of the earbuds into the charging case, the

microphone in the other earbud will be activated.

Bluetooth Pairing with your Device

The earbuds will enter pairing mode when powered on. You are requested to confirm the

connection when you see a pop-up.

Soundcore

Liberty 2 Pro

Soundcore

Liberty 2 Pro

Bluetooth Pairing Request

“Headset” would like

to pair with your Phone

Cancel Pair

Pair

LED behavior (Earbuds)

Flashing white Bluetooth pairing

Steady white for 1 second Bluetooth connected

• In the pairing process, some devices are incompatible with Qualcomm True Wireless

Primary-Secondary dual pairing names, it may notice “connection unsuccessful” when you

tap “Pair” or even no screen popped up. Don’t worry and it will not inuence the using.

• Once successfully paired, the primary earbud connects with your device and transfers

signal to the secondary earbud, the latter one will not connect with your device. As a

result, in the Bluetooth pairing list on your device, it may indicate that only one side is

connected while the other side is not.

Produkspesifikasjoner

Merke:	Soundcore
Kategori:	øreplugg
Modell:	Liberty 2 Pro
Produkttype:	Hodesett
Bluetooth:	Ja
Bluetooth-versjon:	5.0
Tilkoblingsteknologi:	Trådløs
Anbefalt bruk:	Musikk
Impedans:	- Ω
3,5 mm-kontakt:	Nei
Mikrofontype:	Innebygd
USB-tilkobling:	Nei
Ekstra ørepropper:	Ja
Ladekilde:	USB
Ladeetui:	Ja
Batteritype:	Innebygd batteri
Produktfarge:	Sort
Kontrolltype:	Berøringskontroll
Kabler inkludert:	USB Type-C
Batteridrevet:	Ja
Bæremåte:	In-ear
Hodetelefonsfrekvens:	- Hz
Driverenhet:	11 mm
Antall:	1
Øresammenkobling:	Intraaural
Kontinuerlig lyd-playbacktid:	8 timer
Kontinuerlig lydavspillingstid (med ladetaske):	32 timer
Ladetasketype:	Ledning & Trådløs
Tilkoblingstype for ladetaske:	USB Type-C
Øreputer:	Ja
