Soundcore Liberty Air 2 Bruksanvisning

Soundcore øreplugg Liberty Air 2

Les nedenfor 📖 manual på norsk for Soundcore Liberty Air 2 (79 sider) i kategorien øreplugg. Denne guiden var nyttig for 4 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2.5 brukere

Last ned PDF

Side 1/79

USER MANUAL

Soundcore Liberty Air 2

English

Čeština

Dansk

Deutsch

ελληνικά

Español

Suomi

Français

Magyar

Italiano

Nederlands

Norsk

Język polski

Português

Pусский

Slovenský Jazyk

Slovenski Jezik

Svenska

103

Türkçe

109

日本語

115

한국어

121

简体中文

127

繁體中文

133

Portugues do Brasil

139

ةي

عل

145

תי

רב

151

01 EN EN 02

Charging

• Open or close the charging case to activate the LED battery indicator.

• Fully charge both the earbuds and the charging case before the rst-time using.

• To prevent damage, use the provided USB-C cable.

• You can charge the charging case by using a certied wireless charger (not provided).

• Fully dry off the earbuds and the USB port before charging.

< 30%

30% - 70%

> 70%

100%

1 2

Powering On/Off

Open the charging case, the earbuds will automatically power on.

Place the earbuds back into the charging case and close the case, the earbuds will automatically

power off.

ON OFF

1 2

• To manually power on, tap and hold the touchpad on either one of earbuds for 2 seconds

until the LED indicator ashes white once.

• To manually power off, tap and hold touchpad on either one of earbuds for 8 seconds

until the LED indicator ashes red once.

Pairing

True Wireless Stereo Connection

Open the charging case, the earbuds will automatically power on. The right earbud will

automatically connect with the left earbud.

LED behavior (Earbuds)

Breathing white TWS connecting

Steady white for 1 second TWS connected

Bluetooth Pairing with your Device

The earbuds will enter pairing mode when TWS connected or when powered on in mono

mode. You are requested to conrm the connection when you see a pop-up.

Soundcore

Liberty Air 2

Soundcore

Liberty Air 2

Bluetooth Pairing Request

“Headset” would like

to pair with your Phone

Cancel Pair

Pair

LED behavior (Earbuds)

Rapidly ashing white Bluetooth pairing

Slowly ashing white Bluetooth connected

• In the pairing process, some devices are incompatible with Qualcomm True Wireless

Primary-Secondary dual pairing names, it may notice “connection unsuccessful” when you

tap “Pair” or even no screen popped up. Don’t worry and it will not inuence the using.

• Once successfully paired, the primary earbud connects with your device and transfers

signal to the secondary earbud, the latter one will not connect with your device. As a

result, in the Bluetooth pairing list on your device, it may indicate that only one side is

connected while the other side is not.

Produkspesifikasjoner

Merke:	Soundcore
Kategori:	øreplugg
Modell:	Liberty Air 2
Produkttype:	Hodesett
Bluetooth:	Ja
Bluetooth-versjon:	5.0
Tilkoblingsteknologi:	Trådløs
Volumkontroll:	Berøringskontroll
Anbefalt bruk:	Samtaler/musikk
Impedans:	- Ω
3,5 mm-kontakt:	Nei
Mikrofontype:	Innebygd
USB-tilkobling:	Nei
Ekstra ørepropper:	Ja
Ladeetui:	Ja
Fungerer med Google Assistant:	Ja
Batteritype:	Innebygd batteri
Produktfarge:	Hvit
Kabler inkludert:	USB Type-C
Beskyttelsesfunksjoner:	Vannbestandig
Batteridrevet:	Ja
Internasjonal beskyttelses (IP)-kode:	IPX5
Bæremåte:	In-ear
Hodetelefonsfrekvens:	- Hz
Antall:	1
Hodesett-type:	Stereofonisk
Øresammenkobling:	Intraaural
Kontinuerlig lyd-playbacktid:	7 timer
Kontinuerlig lydavspillingstid (med ladetaske):	28 timer
Ladetasketype:	Ledning & Trådløs
