Soundcraft EPM 6 Bruksanvisning

Soundcraft mikser EPM 6

Les nedenfor 📖 manual på norsk for Soundcraft EPM 6 (36 sider) i kategorien mikser. Denne guiden var nyttig for 2 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere

Last ned PDF

Side 1/36

User GuideUser Guide

User Guide

Parts of the design of this product may be protected by worldwide patents.

Part No. ZM0338-01

Soundcraft is a trading division of Harman International Industries Ltd. Information in this manual

is subject to change without notice and does not represent a commitment on the part of the

vendor. Soundcraft shall not be liable for any loss or damage whatsoever arising from the use of

information or any error contained in this manual.

No part of this manual may be reproduced, stored in a retrieval system, or transmitted, in any

form or by any means, electronic, electrical, mechanical, optical, chemical, including photocopying

and recording, for any purpose without the express written permission of Soundcraft.

Harman International Industries Limited

Cranborne House

Cranborne Road

POTTERS BAR

Hertfordshire

EN6 3JN

Tel: +44 (0)1707 665000

Fax: +44 (0)1707 660742

http://www.soundcraft.com

IMPORTANT

Please read this manual carefully before using

your mixer for the first time.

ContentsContents

Contents

User Guide 1

IMPORTANT SAFETY INSTRUCTIONS 4

SAFETY SYMBOL GUIDE 6

OVERVIEW 7

THE 60-SECOND GUIDE 7

INTRODUCTION 9

WIRING UP 10

BLOCK DIAGRAM 14

MONO INPUT CHANNEL 15

STEREO INPUT CHANNELS 18

MASTER SECTION 20

USING YOUR EPM CONSOLE 22

FITTING OPTIONAL RACKMOUNT EARS 24

APPLICATIONS 25

GLOSSARY 28

TYPICAL CONNECTING LEADS 30

MARK-UP SHEETS 32

TYPICAL SPECIFICATIONS 34

WARRANTY 35

Produkspesifikasjoner

Merke:	Soundcraft
Kategori:	mikser
Modell:	EPM 6
Vekt:	6700 g
Bredde:	280 mm
Dybde:	362 mm
Høyde:	90.5 mm
Antall kanaler:	8 kanaler
Produktfarge:	Blå
Hodetelefontilkobling:	3,5 mm
Strømforbruk (vanlig bruk):	20 W
Mikrofon, linje-inn-støpsel:	Ja
Rack-montering:	Ja
Inngangsimpedans mikrofon:	2400 Ω
Utjevner/frekvenskorrigerer:	Ja
Frekvensrekkevidde:	20 - 20000 Hz
XLR utgang:	2
Digital lydbehandling:	- bit
DJ mixer:	Nei
Videofunksjon:	Nei
Udgående opptak:	1
Kanal dempning (1kHz):	96 dB
Antall EQ-bånd pr. kanal:	4
