Side 1/36
1GB2R User Guide
GB2R User Guide
2 GB2R User Guide
© Harman International Industries Ltd. 2007
All rights reserved
Parts of the design of this product may be protected by worldwide patents.
Part No. ZM0351-01 Rev. B
Soundcraft is a trading division of Harman International Industries Ltd. Infor-
mation in this manual is subject to change without notice and does not repre-
sent a commitment on the part of the vendor. Soundcraft shall not be liable for
any loss or damage whatsoever arising from the use of information or any error
contained in this manual.
No part of this manual may be reproduced, stored in a retrieval system, or
transmitted, in any form or by any means, electronic, electrical, mechanical,
optical, chemical, including photocopying and recording, for any purpose with-
out the express written permission of Soundcraft.
Harman International Industries Limited
Cranborne House
Cranborne Road
POTTERS BAR
Hertfordshire
EN6 3JN
UK
Tel: +44 (0)1707 665000
Fax: +44 (0)1707 660742
http://www.soundcraft.com
IMPORTANT
Please read this manual carefully before using
your mixer for the first time.
3GB2R User Guide
Contents
IMPORTANT SAFETY INSTRUCTIONS 4
SAFETY SYMBOL GUIDE 6
Installation 7
MAINS INSTALLATION 7
WORKING SAFELY WITH SOUND 9
Audio Connector Pinouts 12
Introduction 13
Key Features 14
Warranty 15
Block Diagrams 16
Input Channels 16
Master Section / Outputs 17
Using The Console 18
Mono Input 19
Stereo Input - GB2R 12-2 only 20
Master Section 23
Front Panel Connectors 24
Rear Connector Panel 25
Typical Specifications 27
GB2R 12/2 Mark-up Sheet 28
GB2R 16 Mark-up Sheet 30
Dimensions 32
Rack Mounting 33
