SOUNDCRAFT
USER GUIDE
© Harman International Industries Ltd. 1995,1996
All rights reserved
Parts of the design of this product may be protected by worldwide patents.
Part No. ZM0090 Issue 3
Soundcraft is a trading division of Harman International Industries Ltd.
Information in this manual is subject to change without notice and does not represent a
commitment on the part of the vendor. Soundcraft shall not be liable for any loss or damage
whatsoever arising from the use of information or any error contained in this manual.
No part of this manual may be reproduced, stored in a retrieval system, or transmitted, in any
form or by any means, electronic, electrical, mechanical, optical, chemical, including
photocopying and recording, for any purpose without the express written permission of
Soundcraft.
It is recommended that all maintenance and service on the product should be carried out by
Soundcraft or its authorised agents. Soundcraft cannot accept any liability whatsoever for any loss
or damage caused by service, maintenance or repair by unauthorised personnel.
Harman International Industries Ltd.
Cranborne House,
Cranborne Road,
Cranborne Industrial Estate,
Potters Bar,
Herts.,
England.
EN6 3JN.
Tel: 01707 665000
Fax: 01707 660482
Table of Contents
1. Introduction 1.1
Introduction 1.2
Warranty 1.4
2. Installation 2.1
Dimensions 2.2
Precautions and Safety Instructions 2.3
Mains Installation 2.4
General Wiring Procedures 2.5
Connections 2.8
3. Block Diagrams 3.1
Standard Mono Input Module 3.2
Theatre Mono Input Module 3.3
Stereo Input Module 3.4
Dual Group/EQ Output Module 3.5
Dual Group/FX Return Module 3.6
Quad Matrix Module 3.7
Main Module Sheet 1 of 3
3.8
Main Module Sheet 2 of 3
3.9
Main Module Sheet 3 of 3 (Aux Main)
3.10
4. Functional Description 4.1
Standard Mono Input Module 4.2
Theatre Mono Input Module 4.5
Stereo Input Module 4.8
Dual Group/EQ Output Module 4.11
Table of Contents i
