User Guide
Contents
Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . 2
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Basic Principles of PA Mixing . . . . . . . . . . . . . . . . . 4
Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . 7
Audio Connections and Connectors . . . . . . . . . . . 7
Fault Finding Guide . . . . . . . . . . . . . . . . . . . 10
Getting to know your console . . . . . . . . . . . . . . . . 11
Facilities . . . . . . . . . . . . . . . . . . . . . . . . . 11
Input Channel . . . . . . . . . . . . . . . . . . . . . . 11
Stereo Channel . . . . . . . . . . . . . . . . . . . . . . 14
Master Section . . . . . . . . . . . . . . . . . . . . . . 17
Lexicon . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Grahic Equaliser . . . . . . . . . . . . . . . . . . . . . 21
Power Amplifier . . . . . . . . . . . . . . . . . . . . . 23
Patchbay . . . . . . . . . . . . . . . . . . . . . . . . . 25
Using your
POWERSTATION
Console . . . . . . . . . . . 27
Initial Set Up . . . . . . . . . . . . . . . . . . . . . . . 27
Care of your mixer . . . . . . . . . . . . . . . . . . . . . . 29
Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . 31
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Front Panel Layout . . . . . . . . . . . . . . . . . . . . . . 33
Block Diagram . . . . . . . . . . . . . . . . . . . . . . . . . 34
Page 1
Safety Precautions
For your own safety and to avoid invalidation of the
warranty please read this section carefully
The wires in the mains lead are coloured in accordance with
the following code:
Green and yellow:Earth
Blue:Neutral
Brown: Live
As the colours of the wires in the mains lead may not
correspond with the coloured markings identifying the
terminals in your plug, proceed as follows:
The wire which is coloured Green and Yellow must be
connected to the terminal in the plug which is marked
with the letter E or by the earth symbol.
The wire which is coloured Blue must be connected to the
terminal in the plug which is marked with the letter N or
coloured black.
The wire which is coloured Brown must be conected to the
terminal in the plug which is marked with the letter L or
coloured Red.
Ensure that these colour codings are followed carefully in the
event of the plug being changed.
Ensure correct mains voltage is set and correct fuse is
fitted before connecting mains supply. Do not change
mains settings while the mains supply is connected.
The replacement mains power fuse must be the correct
value, as indicated on the unit.
Do not obstruct air vents. Clean air filter at the front of
the unit regularly.
