Soundcraft MH2 Bruksanvisning

Les nedenfor 📖 manual på norsk for Soundcraft MH2 (60 sider) i kategorien Ikke kategorisert. Denne guiden var nyttig for 3 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere

Side 1/60
1
MH2 User GuideMH2 User Guide
MH2 User GuideMH2 User Guide
MH2 User Guide
2
© Harman International Industries Ltd. 2005
All rights reserved
Parts of the design of this product may be protected by worldwide patents.
Part No. ZM0324-01
Soundcraft is a trading division of Harman International Industries Ltd. Information in this manual
is subject to change without notice and does not represent a commitment on the part of the
vendor. Soundcraft shall not be liable for any loss or damage whatsoever arising from the use of
information or any error contained in this manual.
No part of this manual may be reproduced, stored in a retrieval system, or transmitted, in any
form or by any means, electronic, electrical, mechanical, optical, chemical, including photocopying
and recording, for any purpose without the express written permission of Soundcraft.
Harman International Industries Limited
Cranborne House
Cranborne Road
POTTERS BAR
Hertfordshire
EN6 3JN
UK
Tel: +44 (0)1707 665000
Fax: +44 (0)1707 660742
http://www.soundcraft.com
IMPORTANT
Please read this manual carefully before using
your mixer for the first time.
3
ContentsContents
ContentsContents
Contents
IMPORTANT SAFETY INSTRUCTIONS 4
SAFETY SYMBOL GUIDE 6
Introduction 6
Installation 8
Mains Installation 10
Connecting an optional DPS-4 Power Supply Unit 12
WORKING SAFELY WITH SOUND 12
Removing and Refitting the internal Power Supply Module 13
Audio Connector Pinouts 14
Dimensions 15
Using The Console 24
Mono Input Channels 26
Stereo Input Channels 28
Output & Master Section - Overview 32
Grp/Aux 1-8 & FX Returns 33
Notes on Output Solo logic 35
Aux 9-10 Output Section 36
Matrix 1-4 Output Section 37
Master Section 38
Monitor and Headphones Outputs 40
2-Track Replay Input 40
Master Section Rear Connector Panel 40
VCA Master Faders 43
Assignment controls 44
Mute Groups 45
Power Down Settings 46
Clearing The Internal Memory 46
MH2 Typical Specifications 47
Mark-up Sheets 51
MIDI Implementation 55
Mutes 56
Solos 57
Channel Number / MIDI Note Number Listing 59
Warranty 60
