Si Option Slot and Option Card User Guide V2.14
Si Series Option Slot & Card User Guide
Contents
Version: .............................................................................................................................................................................. 2
Supported Cards: ................................................................................................................................................................ 2
Card Installation and Removal: .......................................................................................................................................... 2
Introduction: ....................................................................................................................................................................... 3
Theory of Operation: .......................................................................................................................................................... 3
Example Configurations: .................................................................................................................................................... 3
Card Switch Settings: ......................................................................................................................................................... 5
Si Series MADI Cards ........................................................................................................................................................ 6
Si Series AES Cards ........................................................................................................................................................... 8
Si AVIOM
®
Card ............................................................................................................................................................... 9
Si CobraNet™ Card ......................................................................................................................................................... 10
Si-Series CobraNet™ Card Setup Guide .......................................................................................................................... 11
Si-Series BLU-Si BLU link Card Setup Guide ................................................................................................................ 15
SOUNDCRAFT
A Division of Harman International Industries Ltd
:(676,'(
LONDON
ROAD
HEMEL HEMPSTEAD
HERTS
HP3 9TD
UK
Si Option Slot and Option Card User Guide V2.14
Version:
V1.1 Added AES.
V1.2 Added Aviom® & CobraNet™.
V1.2.1 For initial release.
V1.3.0 Added extra CN info and Installation of hot plugging.
V2.0 Added BLU Link card
V2.1 Updated BLU link information regarding number of consoles on a network
V2.11 Corrected BLU link diagram with PMC16
V2.12 BLU-Si card clock mode corrected (MASTER only)
V2.14 BLU-Si card corrected DIP switch channel numbering in block 33-64 & Contents page ref; address updated
Supported Cards:
MADI, MADI HD, AES, CobraNet™, AVIOM
®
,Multi Digital, BLU Link, DanteCard Installation and Removal:
The opti
on card connectors are located behind blank panels on the rear of the console, use a hex key or Posidrive™
screwdriver to release the cover and retain this for future use.
When installing or removing a card ensure to observe the following:
• Do not over-tighten card retaining screws.
• Observe best practice regarding ESD (electrostatic discharge) before inserting or removing any option card.
• Ensure the console is switched off and all AC power cords are removed before installing or removing any
option card.
• Do not use force; if the card does not locate and plug-in easily contact your distributor or Soundcraft Customer
Service in the UK.
FAILURE TO
OBSERVE THESE PRECAUTIONS MAY RESULT IN DAMAGE TO THE CONSOLE AND /
OR THE OPTION CARD.
