SPEKTRUM DX5e • RADIO USER’S GUIDE

ENDEFRIT

NOTICE

All instructions, warranties and other collateral documents are subject to change at the

sole discretion of Horizon Hobby, Inc. For up-to-date product literature,

visit http://www.horizonhobby.com and click on the support tab for this product.

MEANING OF SPECIAL LANGUAGE:

The following terms are used throughout the product literature to indicate various levels of potential harm when

operating this product:

NOTICE: Procedures, which if not properly followed, create a possibility of physical property damage AND a little or

no possibility of injury.

CAUTION: Procedures, which if not properly followed, create the probability of physical property damage AND a

possibility of serious injury.

WARNING: Procedures, which if not properly followed, create the probability of property damage, collateral damage,

and serious injury OR create a high probability of superﬁcial injury.

WARNING: Read the ENTIRE instruction manual to become familiar with the features of the

product before operating. Failure to operate the product correctly can result in damage to the

product, personal property and cause serious injury.

This is a sophisticated hobby product and NOT a toy. It must be operated with caution and common sense and

requires some basic mechanical ability. Failure to operate this Product in a safe and responsible manner could result

in injury or damage to the product or other property. This product is not intended for use by children without direct

adult supervision. Do not attempt disassembly, use with incompatible components or augment product in any way

without the approval of Horizon Hobby, Inc. This manual contains instructions for safety, operation and maintenance.

It is essential to read and follow all the instructions and warnings in the manual, prior to assembly, setup or use, in

order to operate correctly and avoid damage or serious injury.

WARNING AGAINST COUNTERFEIT PRODUCTS

Thank you for purchasing a genuine Spektrum product. Always purchase from a Horizon Hobby, Inc. authorized

dealer to ensure authentic high-quality Spektrum product. Horizon Hobby, Inc. disclaims all support and warranty

with regards, but not limited to, compatibility and performance of counterfeit products or products claiming

compatibility with DSM or Spektrum.

3SPEKTRUM DX5e • RADIO USER’S GUIDE

EN DE FR IT

TABLE OF CONTENTS

DSMX............................................................... 3

Spektrum DX5e 5-channel DSM

Full Range System ..................................... 4

Transmitter Control Identiﬁcation ..................... 5

DSM Technology .............................................. 6

DSMX Technology ............................................ 6

Receiver Compatibility ..................................... 6

Installing the Transmitter Batteries................... 6

Charging Batteries ............................................ 7

Digital Trims ..................................................... 8

Low Battery Alarm ........................................... 8

Trainer .............................................................. 8

Receiver Installation ......................................... 8

Binding ............................................................. 9

How to Range Test the DX5e .......................... 10

AR600 Failsafe ............................................... 11

How AR600 Failsafe Works ............................11

Servo Reversing ............................................. 11

HI/LO Rate ..................................................... 11

Elevon/ Delta mixing ...................................... 11

France RF Setting ........................................... 12

Receiver Power System Requirements .......... 12

Tips on Using 2.4GHz Systems ......................13

General Information ....................................... 14

Warranty Information .....................................15

FCC Information ............................................. 17

Compliance Information for the

European Union ........................................ 18

Optional Accessories ...................................... 18

FRANCE RF SETTING

The DX5e has a France RF setting that complies with French

regulations. The France RF setting should only be turned on

when operating your transmitter in France outdoors. Please

see page 12 for more details.

DSMX

Spektrum launched the 2.4GHz RC revolution with its DSM2

technology. Since then millions of hobbyists the world over

have come to embrace 2.4 as the way to ﬂy. Spektrum leads

the way yet again with DSMX; the world’s ﬁrst wideband,

frequency-agile 2.4GHz signal protocol.

HOW DOES DSMX WORK?

It’s a crowded 2.4GHz world out there and every 2.4GHz

system faces the same challenges. DSMX better equips you

for these challenges by combining the superior data capacity

and interference resistance of a wideband signal (like that

used in DSM2) with the agility of frequency shifts.

Compared to the wideband signal of DSMX, the narrow

band signal of other frequency hopping 2.4 transmitters is

more likely to suffer data loss in the event of on-channel

interference. Think of it as a river vs. a stream. It takes more

interference to dam a river than it does a stream.

As more and more 2.4 transmitters vie for the same number

of available channels, there is more interference and more of

a risk for data loss. By adding the agility of frequency shifts

to the superior interference resistance of a wideband signal,

DSMX is far less likely to suffer signiﬁcant data loss from

on-channel interference. The result is quicker connection

times and superior response in even the most crowded

2.4GHz environment.

DSMX OPERATIONAL DIFFERENCES

DSMX transmitters and receivers function nearly identically

to Spektrum DSM2 systems. Binding, setting the failsafe,

recording ﬂight log data, as well as general use of the

system is no different than using any current Spektrum

system.

FOLLOWING ARE THE OPERATIONAL

DIFFERENCES:

Brownout Detection- Not Available on DSMX Receivers

DSM2 receivers feature Brownout Detection that ﬂashes the

receiver’s LED if a power interruption occurs. While DSMX

receivers have QuickConnect and recover instantly from

a power interruption, the architecture of DSMX prevents

Brownout Detection when operating in DSMX mode.
