AR9020 User Guide

AR9020 Bedienungsanleitung

AR9020 Guide de l’utilisateur

AR9020 Guida per l’utente

The following terms are used throughout the product literature to indicate various

levels of potential harm when operating this product:

NOTICE: Procedures, which if not properly followed, create a possibility of

physical property damage AND a little or no possibility of injury.

CAUTION: Procedures, which if not properly followed, create the probability of

physical property damage AND a possibility of serious injury.

WARNING: Procedures, which if not properly followed, create the probability

of property damage, collateral damage, and serious injury OR create a high

probability of superﬁcial injury.

NOTICE

All instructions, warranties and other collateral documents are subject to change

at the sole discretion of Horizon Hobby, Inc. For up-to-date product literature,

visit horizonhobby.com and click on the support tab for this product.

Meaning of Special Language

WARNING: Read the ENTIRE instruction manual to become familiar with

the features of the product before operating. Failure to operate the product

correctly can result in damage to the product, personal property and cause serious

injury.

This is a sophisticated hobby product. It must be operated with caution and

common sense and requires some basic mechanical ability. Failure to operate this

Product in a safe and responsible manner could result in injury or damage to the

product or other property. This product is not intended for use by children without

direct adult supervision. Do not attempt disassembly, use with incompatible com-

ponents or augment product in any way without the approval of Horizon Hobby,

Inc. This manual contains instructions for safety, operation and maintenance. It is

essential to read and follow all the instructions and warnings in the manual, prior to

assembly, setup or use, in order to operate correctly and avoid damage or serious

injury.

WARNING AGAINST COUNTERFEIT PRODUCTS

Thank you for purchasing a genuine Spektrum product. Always purchase from a

Horizon Hobby, Inc. authorized dealer to ensure authentic high-quality Spektrum

product. Horizon Hobby, Inc. disclaims all support and warranty with regards, but

not limited to, compatibility and performance of counterfeit products or products

claiming compatibility with DSM or Spektrum technology.

Age Recommendation: Not for children under 14 years.

This is not a toy.

NOTICE: This product is only intended for use with unmanned, hobby-grade, re-

mote-controlled vehicles and aircraft. Horizon Hobby disclaims all liability outside

of the intended purpose and will not provide warranty service related thereto.

WARRANTY REGISTRATION

Visit www.spektrumrc.com/registration today to register your product.

2 3

DSMX

Spektrum launched the 2.4GHz RC revolution with its DSM2™ technology. Since

then, millions of hobbyists the world over have come to embrace 2.4 as the way

to ﬂy. Spektrum leads the way yet again with DSMX—the world’s ﬁrst wideband,

frequency-agile 2.4GHz signal protocol.

How Does DSMX Work?

It’s a crowded 2.4GHz world out there and every 2.4GHz system faces the same

challenges. DSMX better equips you for these challenges by combining the supe-

rior data capacity and interference resistance of a wideband signal (like that used in

DSM2) with the agility of frequency shifts.

Compared to the wideband signal of DSMX, the narrow band signal of other

frequency hopping 2.4 transmitters is more likely to suffer data loss in the event of

on-channel interference. Think of it as a river vs. a stream. It takes more interferen-

ce to dam a river than it does a stream.

As more and more 2.4 transmitters vie for the same number of available channels,

there is more interference and more of a risk for data loss. By adding the agility of

frequency shifts to the superior interference resistance of a wideband signal, DSMX

is far less likely to suffer signiﬁcant data loss from on-channel interference. The

result is quicker connection times and superior response in even the most crowded

2.4GHz environment.

DSMX Operational Differences

DSMX transmitters and receivers function nearly identically to Spektrum DSM2

systems. Binding, setting the failsafe, recording ﬂight log data, as well as general

use of the system is no different than using any current Spektrum system.

Following are the operational differences:

Brownout Detection - Not Available on DSMX Receivers DSM2 receivers feature

Brownout Detection that ﬂashes the receiver’s LED if a power interruption occurs.

While DSMX receivers have QuickConnect

™

technology and recover instantly from

a power interruption, the architecture of DSMX prevents Brownout Detection when

operating in DSMX mode.

Flight Log Recording-Fades Higher than DSM2

Note that DSMX hops through the band while DSM2 ﬁnds two quiet channels and

remains on those channels. Consequently because DSMX operates on quiet and

noisy channels, it’s common to have more Antenna Fades than when using DSM2,

when used in busy 2.4GHz environments. When taking ﬂight log data readings, the

Frames and Hold Data are important and should be used a reference while Fades

are insigniﬁcant due to the nature of frequency hopping. A 10-minute ﬂight will

typically result in less than 50 Frame Losses and no Holds.

Just How Good is DSMX?

In multiple tests, 100 DSMX systems were operated simultaneously for extended

periods of time. During these tests each of the 100 systems was monitored in ﬂight

and on the ground. In every test not a single case of RF link loss, latency increase

or control degradation was experienced or recorded.

Produkspesifikasjoner

Merke:	Spektrum
Kategori:	Fjernkontroll
Modell:	DX9
Innebygd skjerm:	Ja
Vekt:	- g
LED-indikatorer:	Ja
Batterikapasitet:	2000 mAh
Innebygde høyttalere:	Ja
Hodetelefonutganger:	1
Merkekompatibilitet:	Spektrum
Maksimal rekkevidde:	- m
Oppladbar:	Ja
Kompatible produkter:	Spektrum BLADE 450X BNF[BLH4380A]\r\n300 CFX BNF Basic[BLH4650]\r\n300 CFX BNF Basic[BLH4650]\r\nNano QX FPV RTF w/ SAFE[BLH7200]
Antall kanaler:	9 kanaler
Batteriteknologi:	Lithium-Ion (Li-Ion)
Språkversjon:	Engelsk
Produktfarge:	Sort
Av/på-bryter:	Ja
Videoopptaksgrensesnitt:	RF kabel-fri
Display:	LED
Frekvensbånd og driftskanaler:	2.4 GHz
Farge på bakgrunnsbelysning:	Blå
Skjerm med bakgrunnsbelysning:	Ja
Dreiehjul:	Ja
Antall støttede enheter:	1
