StarTech.com SV565UTPUEU Bruksanvisning

StarTech.com Bryter SV565UTPUEU

Les nedenfor 📖 manual på norsk for StarTech.com SV565UTPUEU (20 sider) i kategorien Bryter. Denne guiden var nyttig for 3 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere

Last ned PDF

Side 1/20

USB/VGA Cat 5 UTP

Console Extender

SV565UTPU

SV565UTPUGB

SV565UTPUEU

Instruction Manual

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide rea-

sonable protection against harmful interference in a residential installation. This equip-

ment generates, uses and can radiate radio frequency energy and, if not installed and

used in accordance with the instructions, may cause harmful interference to radio com-

munications. However, there is no guarantee that interference will not occur in a particu-

lar installation. If this equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.s

Increase the separation between the equipment and receiver.s

Connect the equipment into an outlet on a circuit different from that to which the receiver s

is connected.

Consult the dealer or an experienced radio/TV technician for help.s

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and

do not represent an endorsement of a product or service by StarTech.com, or an en-

dorsement of the product(s) to which this manual applies by the third-party company in

question. Regardless of any direct acknowledgement elsewhere in the body of this doc-

ument, StarTech.com hereby acknowledges that all trademarks, registered trademarks,

service marks, and other protected names and/or symbols contained in this manual and

related documents are the property of their respective holders.

Instruction Manual

Table of Contents

Introduction..................................................................... 1

Features ..................................................................................1

System Requirements .............................................................1

Package Contents ...................................................................2

Connecting Your KVM Extender..................................... 3

Preparing Your Site....................................................................3

Installing the Host Unit .............................................................4

Installing the Remote Unit ........................................................5

Video Compensation ..................................................... 6

Using the KVM Extender ................................................ 7

Using the Host Unit ...................................................................7

Using the Remote Unit..............................................................11

Speciﬁcations.................................................................. 14

RJ-45 Connector Pinout ..........................................................14

Accessory Products from StarTech.com ...................... 15

Technical Support........................................................... 16

Warranty Information...................................................... 16

Produkspesifikasjoner

Merke:	StarTech.com
Kategori:	Bryter
Modell:	SV565UTPUEU
Vekt:	299 g
Bruksanvisning:	Ja
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Maksimal oppløsning:	1280 x 1024 piksler
Pakkevekt:	1700 g
Antall USB 2.0-porter:	4
Sertifisering:	CE, FCC, REACH, TAA, UL
AC-inngangsspenning:	100 - 240 V
Senderbredde:	155 mm
Senderdybde:	75 mm
Senderhøyde:	20 mm
Mottakervekt:	299 g
Mottakerbredde:	155 mm
Mottakerhøyde:	20 mm
Produktfarge:	Sort
HD-type:	HD
Pakkedybde:	294 mm
Pakkehøyde:	243 mm
Pakkebredde:	85 mm
AC-adapter utgangsspenning:	9 V
AD-adapter utgangsstrøm:	0.6 A
Kabler inkludert:	KVM
Driftstemperatur (T-T):	0 - 50 °C
Oppbevaringstemperaturomåde (Celsius):	-20 - 60 °C
Bærekraftsertifikater:	RoHS
Harmonisert system (HS)-kode:	84733080
Modell/Type:	Sender og Mottaker
IP-kontroll:	Nei
Antall RJ45-porter:	2
Relativ luftfuktighet under drift (H-H):	0 - 80
Rack-montering:	Nei
Gjennomsnittstid mellom feil (MTBF):	126000 timer
AC-adapter bunt:	Ja
Plugg inn og spill:	Ja
Strømpluggtype:	Type M
Innput-strøm:	0.2 A
Maksimal overføring avstand:	150 m
Maksimal opereringsrekkevidde:	150 m
Sendervekt:	299 g
Video tilkoblingstype:	VGA
Tastatur tilkoblingstype:	USB
Mus tilkoblingstype:	USB
USB port type:	USB Type-A
Mottakerdybde:	75 mm
Strømforbruk (sender) (maks):	5.4 W
Kraftforbruk (mottaker) (max):	5.4 W
Transmitter video tilkoblingstype:	VGA
Sender lokal video tilkoblingstype:	VGA
Sender lokal video tilkobling:	Ja
