Side 1/13

STRATUS

1 2

COMPATIBILITY - Requires iOS 7 or later on one of the following devices:

• iPhone® 5, iPhone 5c, iPhone 5s or later.

• iPad® mini, iPad mini with Retina, iPad air, iPad 4th generation or later.

• iPod® touch 5th generation or later.

CONTENTS

USB CABLE

COVER

CONTROLLER

MORE INFO

FAQ.STEELSERIES.COM

SUPPORT.STEELSERIES.COM

SHOP.STEELSERIES.COM

3 4

The Stratus will remember the last paired iOS Device. When you reset the power on the Stratus, it will automatically connect to the last

paired iOS device.

If you are already connected to an iOS device and want to change the device that you’re playing on, there are two ways to do this, as follows:

1. If you want to erase the history of all the devices stored on your controller, hold down the pairing button on the back of the controller

for 5 seconds. The LED’s should blink 1 and 3 followed by 2 and 4. This means that all of the history stored in the controller has been

erased, it will enter pairing mode, and it will search for new iOS Devices (refer to the image below).

2. If you want the controller to enter “pairing mode” without erasing prior history, press the pairing button for 2 seconds. The LED’s

should blink 1 and 2 followed by 3 and 4. This means that the controller is in pairing mode and will search for new devices (refer to

the image below).

Please go to www.steelseries.com/stratus/faq for more detailed product information.

When the USB Cable is connected, the LED’s will blink in a distinct manner to indicate that the device is charging.

ADDITIONAL NOTES

WEIGHT:

apple_controller-11-6-2013

PROPRIETARY AND CONFIDENTIAL

THE INFORMATION CONTAINED IN THIS

DRAWING IS THE SOLE PROPERTY OF

<INSERT COMPANY NAME HERE>. ANY

REPRODUCTION IN PART OR AS A WHOLE

WITHOUT THE WRITTEN PERMISSION OF

<INSERT COMPANY NAME HERE> IS

PROHIBITED.

COMMENTS:

SHEET 1 OF 1

Q.A.

MFG APPR.

ENG APPR.

CHECKED

DRAWN

DATE

NAME

DIMENSIONS ARE IN INCHES

TOLERANCES:

FRACTIONAL

ANGULAR: MACH

BEND

TWO PLACE DECIMAL

THREE PLACE DECIMAL

NEXT ASSY

USED ON

APPLICATION

DO NOT SCALE DRAWING

FINISH

MATERIAL

RE V.

DWG. NO.

SIZE

SCALE:1:2

WEIGHT:

apple_controller-11-6-2013

PROPRIETARY AND CONFIDENTIAL

THE INFORMATION CONTAINED IN THIS

DRAWING IS THE SOLE PROPERTY OF

<INSERT COMPANY NAME HERE>. ANY

REPRODUCTION IN PART OR AS A WHOLE

WITHOUT THE WRITTEN PERMISSION OF

<INSERT COMPANY NAME HERE> IS

PROHIBITED.

COMMENTS:

SHEET 1 OF 1

Q.A.

MFG APPR.

ENG APPR.

CHECKED

DRAWN

DATE

NAME

DIMENSIONS ARE IN INCHES

TOLERANCES:

FRACTIONAL

ANGULAR: MACH

BEND

TWO PLACE DECIMAL

THREE PLACE DECIMAL

NEXT ASSY

USED ON

APPLICATION

DO NOT SCALE DRAWING

FINISH

MATERIAL

REV.

DWG. NO.

SIZE

SCALE:1:2

1. Turn on controller

2. LEDs will light up solid for the ﬁrst ﬁve seconds, indicating battery life as follows:

3. All four LEDs will ﬂash ON and OFF evenly when the Controller is not paired.

4. To pair the Controller, go to your iOS device and follow the User Interface ﬂow below:

Settings > Turn On Bluetooth > Search for new Devices

“SteelSeries Stratus” will display on the screen. Click to Connect via Bluetooth

5. If the Controller has paired successfully, the LEDs will ﬂash ON and OFF unevenly (rapidly).

6. If the Controller is paired and the user starts a game, one of the four LEDs will light up solid, depending on the player number (1-4)

assigned.

7. When the Controller battery charge gets low (~20 minutes remaining), the LEDs will start ﬂashing continuously for 5 seconds, even if

in game mode. This behavior will keep repeating until the battery charge increases to 10%.

INITIALIZATION

Produkspesifikasjoner

Merke:	Steelseries
Kategori:	kontroll
Modell:	Stratus
Vekt:	75 g
Bredde:	110 mm
Høyde:	60 mm
LED-indikatorer:	Ja
Batterikapasitet:	380 mAh
Tilkoblingsteknologi:	Trådløs
Antall knapper:	13
Batteriteknologi:	Lithium-Ion (Li-Ion)
Batteritype:	Innebygget
Produktfarge:	Sort
Antall støttede batterier:	1
Batteriliv (maks.):	10 timer
Enhetsgrensesnitt:	Bluetooth
Enhetstype:	Gamepad
Rekkevidde trådløs ruter:	6 m
Støttede spillplattformer:	iOS
Spillkontrollerteknologi:	Digitalt
