Side 1/4
2060 Whitfield Park Ave., Sarasota, FL 34243 800.826.5537 fax 941.755.6529 | | | Commercial-Industrial
@
stiebel-eltron-usa.com | www.stiebel-eltron-usa.com
rev. 10.2023 Due to our continuous process of engineering and technological advancement, specifications may change without notice.|
Specications
ENGINEERING SPECIFICATION SHEET
Certified to ANSI/UL Std. 499
Conforms to CAN/CSA
Std. C22.2 No.88
W
A
R
R
A
N
T
Y
6
/
2
L
I
M
I
T
E
D
6 years against leakage /
2 years against defects in
workmanship & materials
Model Part Number Voltage Phase kW 3P BreakerAmps
Size (A)
Temperature Rise °F
3 gpm 4 gpm 5 gpm 10 gpm 20 gpm
CF Plus
48 kW
CFPLUS-048-208 208 3-phase delta 45.07 125.09 150 15>100 77 62 31
CFPLUS-048-240 240 3-phase delta 50.00 150120.28 >100 85 68 34 17
CFPLUS-048-480 480 3-phase delta 50.00 60.14 70 >100 85 68 34 17
CFPLUS-048-575 575 3-phase delta 47.99 48.19 60 >100 82 66 33 16
CF Plus
54 kW
CFPLUS-054-208 208 3-phase delta 54.08 150.11 92175 >100 74 37 18
CFPLUS-054-240 240 3-phase delta 54.05 130.02 150 92>100 74 37 18
CFPLUS-054-480 480 803-phase delta 54.05 65.01 >100 92 74 37 18
CF Plus
60 kW
CFPLUS-060-208 208 2003-phase delta 63.09 175.13 >100 >100 86 43 22
CFPLUS-060-240 240 3-phase delta 60.00 144.34 175 >100 >100 82 41 21
CFPLUS-060-480 480 803-phase delta 60.00 72.17 >100 >100 82 41 21
CF Plus
72 kW
CFPLUS-072-208 208 3-phase delta 72.00 199.85 225 25>100 >100 98 49
CFPLUS-072-240 240 3-phase delta 72.00 173.21 200 >100 >100 98 49 25
CFPLUS-072-480 480 3-phase delta 72.00 86.60 100 >100 >100 98 49 25
CFPLUS-072-575 575 3-phase delta 72.00 72.29 80 >100 >100 98 49 25
CF Plus Series: 48 kW, 54 kW, 60 kW, 72 kW | NEMA 4/4X
Model CF Plus 48 kW, CF Plus 54 kW, CF Plus 60 kW, CF Plus 72 kW
Phase 3-phase
Inlet/outlet pipe connection ¾˝ or 1˝ female NPT
Heat exchanger material 316L stainless steel
Enclosure rating NEMA 4 shown, NEMA 4X available
Operating pressure range 4–145 psi (0.28–10 bar)
Temperature setpoint options
(programmed at factory, user adjustable)
60–180 °F (32–82 °C)
Number of heating elements 12
Minimum activation flow (hot start) 2.0 gpm (7.6 l/m) for DN 20 flowmeter
3.75 gpm (14.2 l/m) for DN 25 flowmeter
Maximum flow at 60 psi 22.5 gpm (85.2 l/m) for DN 20 flowmeter
40 gpm (151.4 l/m) for DN 25 flowmeter
2060 Whitfield Park Ave., Sarasota, FL 34243 800.826.5537 fax 941.755.6529 | | | Commercial-Industrial
@
stiebel-eltron-us.com | www.stiebel-eltron-usa.com
rev. 10.2023 Due to our continuous process of engineering and technological advancement, specifications may change without notice.|
Dimensions
38-13/32"
14"
3-15/16"
3-3/4"
13-9/16"
35-19/32"
27-31/32"
37-9/32"
36"
22-1/2"
24"
¾˝ connection
2060 Whitfield Park Ave., Sarasota, FL 34243 800.826.5537 fax 941.755.6529 | | | Commercial-Industrial
@
stiebel-eltron-usa.com | www.stiebel-eltron-usa.com
rev. 10.2023 Due to our continuous process of engineering and technological advancement, specifications may change without notice.|
38-13/32"
14"
3-15/16"
3-5/8"
13-9/16"
37-9/32"
36"
22-1/2"
24"
37-1/2"
28-11/32"
1˝ connection
