Side 1/22

Before contacting, you must have the following:

Serial no., model no., store no., store address, details (photos, leak locations,

damage, store’s ambient conditions, etc.)

Support: structuralconcepts.com/support

Tech Service/Warranty: 1 (800) 433-9490, EXT. 1

Hours: Monday – Friday, 8am to 8pm EST (Closed holidays)

21-35145 FUSION GHSS REFRIGERATED CASES MANUAL-EN REV C DATE: 05/22/25

Fusion® User Manual

PART NUMBER: 21-35145

Please Note

Your specic model number is located on the

serial label (usually at the case rear). However,

label locations may vary depending on the

model – see page 20 for more details.

Models shown on this cover sheet do not

represent all models covered by this manual.

Models

GHSS460R

GHSS456R

GHSS556R

GHSS656R

GHSSEH452RSC.6235

GHSSEH452RSC.7819

GHSS660R

Fusion® User Manual 2

Overview / Type / Compliance / Warnings / Precautions / Wiring / Plugs .............................................................................. 3-5

Installation: Case Removal From Skid .............................................................................................................................................6-7

Installation: Start Up ..............................................................................................................................................................................8

Placement of Case ................................................................................................................................................................................9

Product Placement .............................................................................................................................................................................. 10

Shelf and Deck Load Limits .................................................................................................................................................................. 11

Front Panel Removal ............................................................................................................................................................................12

Rear Panel Removal .............................................................................................................................................................................13

Cleaning Schedule (To Be Performed by Store Personnel) ........................................................................................................... 14

Preventative Maintenance ............................................................................................................................................................15-19

Serial Label Information & Location ..................................................................................................................................................20

Programmable Controller Information ..............................................................................................................................................21

Technical Service Contact Information / Warranty Information ..................................................................................................22

Table of Contents
