FUSION SELF-SERVICE JUNIOR CUB COOLERS (REMOTE UNITS ONLY)
REV F DATE: 07/13/2023
USER MANUALS\20-35614_FUSION_USER MANUAL_GJDSS(L)RLB_REF_SELF-SVC_JR CUB COOLER
Please note the following:
1. Your specific model number is located on serial label
(usually at case rear).
2. See SERIAL LABEL LOCATION & INFORMATION section
in this manual for sample labels.
3. This operating manual is applicable to the following
models: GJDSS3RLB, GJDSS4RLB, GJDSS5RLB,
GJDSS6RLB, GJDSS8RLB, GJDSS10RLB and
GJDSS12RLB. It may also be applicable to models that
are not listed herein.
Model GJDSS6RLB
Model GJDSS10RLB
(Similar To Model GJDSS12RLB)
Model GJDSS3RLB
SCC P/N
20-35614
USER
MANUAL
FUSION
CAREFULLY FOLLOW THESE INSTRUCTIONS
Structural Concepts Corp. ∙ 888 E. Porter Rd ∙ Muskegon, MI 49441 Phone: 231.798.8888 Fax: 231.798.4960 ∙ www.structuralconcepts.com
2
TABLE OF CONTENTS
TABLE OF CONTENTS ………………………………………………………………………………………...
OVERVIEW / TYPE 1 vs. 2 / COMPLIANCE / WARNINGS / PRECAUTIONS / WIRING / PLUGS …...
INSTALLATION: REMOVAL FROM SKID / REMOVING LOWER FRONT PANELS ..……...…………..
INSTALLATION: BOLTING AND CAULKING UNITS TOGETHER (OPTIONAL) …………….………….
INSTALLATION: FIELD SERVICE CONNECTION SPACE REQUIREMENTS ………………………….
INSTALLATION: UNDERSIDE FIELD ACCESS COMPONENTS (MODEL GJDSS6RLB
DISPLAYED.……………….. …….………………………………………………………….………....
INSTALLATION: FRAME SUPPORT RAILS / SEALING TO FLOOR ……………………………………..
INSTALLATION: REFRIG. LINE & DRAIN STUB-UP CONNECTION - MODEL GJDSS6RLB ONLY ...
INSTALLATION: REFRIG. LINE & DRAIN STUB-UP CONNECTION - MODEL GJDSS8RLB ONLY ...
INSTALLATION: REFRIG. LINE & DRAIN STUB-UP CONNECTION - MODEL GJDSS12RLB ONLY .
INSTALLATION: REFRIG. LINE & DRAIN STUB-UP CONNECTION - MODEL GJDSS12RLB ONLY..
INSTALLATION: DISPLAY CASE START-UP / LIGHTS / THERMOMETER / TEMP. CONTROLLER..
REFRIGERATED AREA: AXIAL FANS / DRAIN / TXV / BALL VALVE / SHUTOFF VALVE /
REFRIGERATION LINE AND WIRING ROUTES …………………………………………………..
GENERAL CLEANING (TO BE PERFORMED BY STORE PERSONNEL) ………………..……...……..
TROUBLESHOOTING (TO BE PERFORMED BY STORE PERSONNEL) ..………..…….……….…….
GENERAL CLEANING (BY TRAINED SERVICE PROVIDERS ONLY) ……………………...……...…...
TROUBLESHOOTING (BE PERFORMED BY TRAINED SERVICE PROVIDERS ONLY) ………..…...
HONEYCOMB AIR DIFFUSER REMOVAL/INSTALLATION (TO BE PERFORMED BY TRAINED
SERVICE PROVIDER ONLY) …..……………………………………………………………………..
SERIAL LABEL INFORMATION & LOCATION ..……………………………………...…....…………..…...
TECHNICAL SERVICE CONTACT INFORMATION / WARRANTY INFORMATION ....……….….........
2
3-4
5
6
7
8
9
10
11
12
13
14
15-16
17
18-19
20
21-22
23
24
25
