Before contacting, you must have the following:

Serial no., model no., store no., store address, details (photos, leak locations,

damage, store’s ambient conditions, etc.)

Support: structuralconcepts.com/support

Tech Service/Warranty: 1 (800) 433-9490, EXT. 1

Hours: Monday – Friday, 8am to 8pm EST (Closed holidays)

21-35149 FUSION REFRIGERATED CASES MANUAL-EN REV D DATE: 7/16/25

Fusion® User Manual

PART NUMBER: 21-35149

Please Note

Your specic model number is located on the

serial label (usually at the case rear). However,

label locations may vary depending on the

model – see page 30 for more details.

Models shown on this cover sheet do not

represent all models covered by this manual.

Models

GHS456R

GHS556R

GHS656R

GLDS4R

GLDS5R

GLDS6R

GMDS4R

GMDS5R

GMDS6R

GMDSV4R

GMDSV4RA

GMDSVX4RA

GMDSV5R

GMDSV6R

GMDSV6RA

GMDSV8RA

GMDSV12RA

GLDS4R

Fusion® User Manual 2

Overview / Type / Compliance / Warnings / Precautions / Wiring / Plugs .............................................................................. 3-5

Installation: Case Removal From Skid .............................................................................................................................................6-7

Installation: Start Up ..............................................................................................................................................................................8

Placement of Case ................................................................................................................................................................................9

Product Placement ......................................................................................................................................................................... 10-12

Shelf and Deck Load Limits ..................................................................................................................................................................13

Lower Front Panel Removal ................................................................................................................................................................ 14

Rear Panel Removal ............................................................................................................................................................................ 15

Atmosphere System Requirements and Operation .................................................................................................................. 16-17

Atmosphere Cleaning And Maintenance .................................................................................................................................. 18-23

Cleaning Schedule (To Be Performed by Store Personnel) ...........................................................................................................24

Preventative Maintenance .......................................................................................................................................................... 25-29

Serial Label Information & Location ..................................................................................................................................................30

Programmable Controller Information ..............................................................................................................................................31

Technical Service Contact Information / Warranty Information ..................................................................................................32

Table of Contents
