Rev J Date: 1.14.2020
Operating Manuals\Reveal_Free Standing Refrig Self-Service Cases 20-78252.pub
SCC P/N
20-78252
INSTALLATION
& OPERATING
MANUAL
REVEAL® FREE STANDING SELF-SERVICE
REFRIGERATED MERCHANDISERS
> SELF-CONTAINED OR REMOTE UNITS
> CAUTION! DO NOT PUSH OR PULL ON END PANELS!
> ONLY USE HANDLES (ON CASE) TO PUSH OR PULL
CASE INTO POSITION!
> SINGLE ACCESS MODELS: REAR SLIDING DOORS
WITH PERFORATED PLENUMS OR SOLID BACK PANELS
> DUAL ACCESS MODELS: BACK-TO-BACK
PERFORATED PLENUMS
> SEE PAGES 10-11 FOR PANEL, GRILLE & TOE-KICK
ATTACHMENT INSTRUCTIONS
Model With Rear Sliding Doors and Acrylic
Perforated Plenums (Cladding Attached)
Perforated Rear Panel Model Shown (Cladding Attached)
Models Are Shipped WITHOUT Panels and
Cladding Attached. See Pages 10 and 11
for Component Attachment Instructions.
Structural Concepts Corporation ∙ 888 E. Porter Road ∙ Muskegon, MI 49441 Phone: 231.798.8888 Fax: 231.798.4960 ∙ www.structuralconcepts.com
Perforated Rear Panel Model Shown (Cladding
Removed For Illustrative Purposes Only)
Reveal
®
READ AND SAVE THESE INSTRUCTIONS
Dual Access Model With Perforated Back-To-Back
Rear Panels (Cladding Remove For
Illustrative Purposes Only)
2
TABLE OF CONTENTS
TABLE OF CONTENTS …………………………………………………………………………………...…...
REVEAL® FREE STANDING REFRIGERATED SELF-SERVICE MODEL APPLICABILITY AND
INDIVIDUAL MODEL DIMENSIONS ……………...………………………………………………...
OVERVIEW / DISPLAY TYPE I vs. II / COMPLIANCE / WARNINGS / PRECAUTIONS ……………...
INSTALLATION: TOE-KICK & AIR INTAKE GRILLE REMOVAL / DISCONNECTING CASE FROM
PALLET ...…...………………………………………………………………………………………….
INSTALLATION, CONT’D.: CASTER ADJUSTMENT / LOCK / UNLOCK / CASE REMOVAL
FROM PALLET .……….………………………………………………………………………..……...
INSTALLATION, CONT’D: SHELVING ASSEMBLY COMPONENTS ...………………………………...
INSTALLATION, CONT’D: PLUG IN UNIT / MAIN POWER SWITCH / TURN ON LED LIGHTS ...….
INSTALLATION, CONT’D: SHIPPING BRACE / ATTACHING FRONT PANEL COMPONENTS /
HANDLES …….…………………………………………………………..…………………………….
INSTALLATION, CONT’D: ATTACHING SIDE PANELS, REAR PANEL AND REAR GRILLE ……..
INSTALLATION, CONT’D: OPTIONAL ACRYLIC SECURITY COVER ………………………………...
CASE DESIGN: FRONT VIEW OF FREE STANDING, SELF-SERVICE MERCHANDISERS ............
CASE DESIGN, CONT’D: REAR VIEW OF FREE STANDING, SELF-SERVICE MERCHANDISERS
CASE DESIGN, CONT’D: CONTROLLER / DC DRIVERS / MAIN POWER SWITCH /
CONDENSER COIL FILTER ….………………………………………………………………………
CASE DESIGN, CONT’D: NIGHT CURTAIN ACCESS AND OPERATION …………………………….
CASE DESIGN, CONT’D: TUB AREA (AFTER DECK PAN REMOVAL) ……………………………….
CASE DESIGN, CONT’D: LED LIGHT SWITCH LOCATIONS / LED LIGHTS / THERMOMETER ….
CASE DESIGN, CONT’D: REAR SLIDING DOOR REMOVAL / REAR PERFORATED PLENUM
CONTROL ………………………………………………………………………………………………
CASE DESIGN, CONT’D: CONDENSER PACKAGE (SELF-CONTAINED UNITS ONLY) …………..
PRODUCT PLACEMENT / HONEYCOMB AIRFLOW CONSIDERATION / LOAD LINES …………...
CLEANING SCHEDULE (TO BE PERFORMED BY STORE PERSONNEL) ..…....…...…………...….
PREVENTIVE MAINTENANCE (TO BE PERFORMED BY TRAINED SERVICE PROVIDER) ……....
TROUBLESHOOTING (TO BE PERFORMED BY STORE PERSONNEL ONLY) ...………………......
TROUBLESHOOTING (TO BE PERFORMED BY TRAINED SERVICE PROVIDERS ONLY) ……….
TROUBLESHOOTING (TO BE PERFORMED BY TRAINED SERVICE PROVIDERS ONLY) -
CONDENSING SYSTEM ..………………………………………………………………………...….
TROUBLESHOOTING (TO BE PERFORMED BY TRAINED SERVICE PROVIDERS ONLY) -
EVAPORATOR SYSTEM ...…………………………………………………………………………...
SERIAL LABEL INFORMATION & LOCATION ..…………………………….……...…....……………..…
TEMPERATURE CONTROLLER - CAREL® ...…..……………………..…….……………………..……..
TECHNICAL SERVICE CONTACT INFORMATION & WARRANTY INFORMATION ...…...…...….....
2
3
4-5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23-25
26-27
28-31
32
33
34
35-37
38
