Rev C Date: 9.28.2018
Operating Manuals\Reveal_Countertop_Dry (Ambient)_Service_Cases_20-91211.pub
Structural Concepts Corporation ∙ 888 E. Porter Road ∙ Muskegon, MI 49441 Phone: 231.798.8888 Fax: 231.798.4960 ∙ www.structuralconcepts.com
SCC P/N
20-91211
READ AND SAVE
INSTALLATION
& OPERATING
MANUAL
REVEAL® COUNTERTOP, DRY (AMBIENT) MERCHANDISERS
> SERVICE MODELS (SHOWN)
> REAR SLIDING/REMOVABLE DOORS
> ADJUSTABLE GLASS SHELVES
> CAUTION! DO NOT PUSH OR PULL ON GLASS ENCLOSURE!
> ONLY USE UPRIGHTS (AT EACH END OF CASE) TO PUSH OR PULL CASE INTO POSITION!
Model NR4835DSV Shown Above
Model NR4827DSV Shown Atop
Customer Countertop
Reveal
®
2
TABLE OF CONTENTS
TABLE OF CONTENTS …………………………………………………………………………………...…...
OVERVIEW / COMPLIANCE / LAMP REPLACEMENT / ELECTRICAL HAZARD WARNING /
WIRING DIAGRAM ……………………………………………………………………..……………...
WEIGHT LOAD ON GLASS - PREVENTING SAGGING / SEALING COUNTER-MOUNTED UNITS..
REVEAL® COUNTERTOP DRY (AMBIENT) SERVICE & SELF-SERVICE MODEL
APPLICABILITY & DIMENSIONS ……………...…………………………………………………...
INSTALLATION: COMPONENT REMOVAL / REMOVAL OF CASE FROM PALLET AND ONTO
COUNTER ...…………………………………………………………………………………………….
INSTALLATION, CONT’D: COMPONENT PLACEMENT / PLUG / LIGHTS / COUNTER
ATTACHMENT …………………………………………………………………………………………
INSTALLATION, CONT’D: SHELVING ASSEMBLY COMPONENTS …………………………………..
CASE DESIGN: GLASS ENCLOSURE / GLASS SHELVING AND BRACKETRY .…………………...
CASE DESIGN, CONT’D: PLUG & CORD / LED LIGHTS & SWITCH FIXTURES / REAR SLIDING
DOORS ………………………………………………………………………………………………….
CLEANING SCHEDULE (TO BE PERFORMED BY STORE PERSONNEL) ..…....…...…………...….
TROUBLESHOOTING (TO BE PERFORMED BY STORE PERSONNEL) .………..………………......
TROUBLESHOOTING (TO BE PERFORMED BY TRAINED SERVICE PROVIDERS ONLY) ……….
SERIAL LABEL INFORMATION & LOCATION ..…………………………….……...…....……………..…
TECHNICAL SERVICE CONTACT INFORMATION & WARRANTY INFORMATION ...…...…...….....
2
3
4
5
6
7
8
9
10
11
12
13
14
15
