Side 1/27
REV-F DATE: 01/10/25 21-33895 OASIS REF SELF-SERVICE B BN C CN-EN
READ AND SAVE THESE INSTRUCTIONS
Important!
See Counter
Installation Guide
Section In This
Manual Before
Proceeding With
Installation!
SELF-SERVICE REFRIGERATED MERCHANDISERS
USER MANUAL
21-33895
OASIS
®
Structural Concepts Corp. ∙ 888 E. Porter Rd ∙ Muskegon, MI 49441 Phone: 231.798.8888 Fax: 231.798.4960 ∙ www.structuralconcepts.com
Model B37R
Model C33R
Models Represented In This Operating Manual*
C33R, C43R, C53R, CN33R, CN43R, CN53R, B37R, B47R, B57R, B67R, BN37R, BN47R,
BN47R.8128, BN47R.8128A, BN57R, B35R, B45R, B55R, B65R
* This Manual May Also Be Applicable To Models Not Listed Herein.
TABLE OF CONTENTS
2
TABLE OF CONTENTS ………………………………………………………………………………………..
OVERVIEW / TYPE / COMPLIANCE / WARNINGS / PRECAUTIONS / WIRING / PLUGS ……....…..
SHIPPING BRACKET REMOVAL / TOE-KICK REMOVAL / REMOVAL FROM SKID / CASE
ALIGNMENT …………………………………………………………………………………….………
SHIMMING FRAME SUPPORT RAILS / ADJUSTING LEVELERS ………………………………………
LOAD LEVEL & TEMPERATURE GUIDE .………………………………………………………………….
SHELF AND DECK LOAD LIMITS………..………………………………………………………………….
START-UP AND OPERATION: THERMOSTAT / MAIN POWER SWITCH / LIGHTS SWITCH /
FILTER .......................................................................................................................................
REFRIGERATION - REAR CONDENSATE PACKAGE ACCESS (NO SCREW REMOVAL
REQUIRED) ………………………………………………………………………………………….….
REFRIGERATION - FRONT CONDENSATE PACKAGE ACCESS (NO SCREW REMOVAL
REQUIRED) ……………………………………………………………………………………………..
REFRIGERATION - CONDENSATE PACKAGE ILLUSTRATED PARTS BREAKDOWN
……………………………………………………………………………………………………………………..
GENERAL CLEANING (TO BE PERFORMED BY STORE PERSONNEL) ………………..…………...
PREVENTIVE MAINTENANCE (TO BE PERFORMED BY TRAINED SERVICE PROVIDERS
ONLY) …………………………………………………………………………………………………...
TROUBLESHOOTING (TO BE PERFORMED BY STORE PERSONNEL) …...………………………..
SERIAL LABEL & LOCATION / TECHNICAL INFORMATION / ADD’L INFORMATION ...............….
PROGRAMMABLE CONTROLLER INFORMATION….……………………………………..…….……....
SCC TECHNICAL SERVICE CONTACT INFORMATION / LIMITED WARRANTY ………………..…
2
3-5
6
7
8-9
10
11
12
13
14
15
16-22
23-24
25
26
27
Models Represented In This Operating Manual*
C33R, C43R, C53R, CN33R, CN43R, CN53R, B37R, B47R, B57R, B67R, BN37R, BN47R,
BN47R.8128, BN47R.8128A, BN57R, B35R, B45R, B55R, B65R
* This Manual May Also Be Applicable To Models Not Listed Herein.
