Before contacting, you must have the following:

Serial no., model no., store no., store address, details (photos, leak locations,

damage, store’s ambient conditions, etc.)

Support: structuralconcepts.com/support

Tech Service/Warranty: 1 (800) 433-9490, EXT. 1

Hours: Monday – Friday, 8am to 8pm EST (Closed holidays)

21-35298 OASIS REFRIGERATED SELF-SERVICE/COMBO-EN REV E DATE: 8/21/25

Oasis® User Manual

PART NUMBER: 21-35298

Please Note

Your specic model number is located on the

serial label (usually at the case rear). However,

label locations may vary depending on the

model – see page 20 for more details.

Models shown on this cover sheet do not

represent all models covered by this manual.

Models

B24R

CO2739R

COU2757R

COU2765R

C3Z3667

C3Z4867

Q344R

Q45N44AR

COU2757R

Oasis® User Manual 2

Overview / Type / Compliance / Warnings / Precautions / Wiring / Plugs .............................................................................. 3-5

Installation: Case Removal From Skid .............................................................................................................................................6-7

Installation: Start Up ..............................................................................................................................................................................8

Placement of Case ................................................................................................................................................................................9

Product Placement .............................................................................................................................................................................. 10

Shelf and Deck Load Limits .................................................................................................................................................................. 11

Lower Front Panel Removal .................................................................................................................................................................12

Rear Panel Removal .............................................................................................................................................................................13

Cleaning Schedule (To Be Performed by Store Personnel) ........................................................................................................... 14

Preventative Maintenance ............................................................................................................................................................15-19

Serial Label Information & Location ..................................................................................................................................................20

Programmable Controller Information ..............................................................................................................................................21

Technical Service Contact Information / Warranty Information ..................................................................................................22

Table of Contents
