Side 1/25
REV D DATE: 06/23/2023
21-26059_REVEAL_USER MANUAL_NE(L)(H)HSSV_HTD_SELF-SVC_SLIDE-IN_CASE
SCC P/N
21-26059
REVEAL® SLIDE-IN SELF-SERVICE HEATED MERCHANDISERS
> REAR SLIDING DOOR UNITS WITH PERFORATED PLENUMS THAT SLIDE IN TANDEM WITH DOORS
> SOLID BACK UNITS WITH FIXED METAL PERFORATED PLENUMS
> CAUTION! DO NOT PUSH OR PULL ON UPPER GLASS ENCLOSURE!
> ONLY USE HANDLES (AT EACH END OF CASE) TO PUSH OR PULL CASE INTO POSITION!
Reveal
®
USER
MANUAL
READ AND SAVE THESE INSTRUCTIONS
Model NE4835HSSV Slide-In Unit Shown With
Solid Perforated Metal Back and 3 Shelves
(Illustration Shown May Not Reflect Every
Feature Or Option of Your Particular Case)
Important! See Structural Concepts
Reveal® Self-Service Counter Guide
P/N 21-26260 (That Accompanies This
Manual) For Cabinetry Construction/
Design Requirements.
Model NE4835HSSV Slide-In Unit Shown With
Rear Sliding Doors and 3 Shelves
(Illustration Shown May Not Reflect Every
Feature Or Option of Your Particular Case)
Structural Concepts Corp. ∙ 888 E. Porter Rd ∙ Muskegon, MI 49441 Phone: 231.798.8888 Fax: 231.798.4960 ∙ www.structuralconcepts.com
2
TABLE OF CONTENTS
TABLE OF CONTENTS …………………………………………………………………………………...…...
REVEAL® FREE STANDING HEATED SELF-SERVICE MODEL APPLICABILITY &
DIMENSIONS ....………………………………………………………………………………………..
REVEAL® SLIDE-IN SELF-SERVICE HEATED MODEL APPLICABILITY & DIMENSIONS ....……..
INSTALLATION: DISCONNECTION/REMOVAL OF CASE FROM SKID / REVIEW CASE
SURROUNDINGS ……………………………………………………………………………….……..
INSTALLATION, CONT’D: SHELVING ASSEMBLIES / SHELVING RETAINER CLIP REMOVAL ...
INSTALLATION, CONT’D: PLUG IN UNIT / MAIN POWER SWITCH AND LED LIGHT SWITCH .....
CASE DESIGN & FIELD SERVICE PARTS LIST: CASE FRONT AND REAR VIEWS ……….………
CASE DESIGN & FIELD SERVICE PARTS LIST, CONT’D: ELECTRICAL BOX COMPONENTS ....
CASE DESIGN & FIELD SERVICE PARTS LIST, CONT’D: HEATER / DECKS / BAFFLE / AIR
DEFLECTOR ………………………………………………………………………………..….……….
CASE DESIGN & FIELD SERVICE PARTS LIST, CONT’D: SHELVING ASSEMBLY COMPONENTS
CASE DESIGN & FIELD SERVICE PARTS LIST, CONT’D: LED LIGHT / PLUG / THERMOMETER ..
CASE DESIGN & FIELD SERVICE PARTS LIST, CONT’D: REAR PIKE DOORS / REAR
PERFORATED PLENUM DOORS ………………………………………………...…….…….....….
CASE STARTUP / HEATER SETTINGS / LIGHTS SWITCH / SHUTTING DOWN CASE .……………
PRODUCT PLACEMENT / AIRFLOW CONSIDERATION / LOAD LINES ………………………….…..
CLEANING SCHEDULE (TO BE PERFORMED BY STORE PERSONNEL) ..…....…...…………...….
PREVENTIVE MAINTENANCE (TO BE PERFORMED BY TRAINED SERVICE PROVIDER) ……....
TROUBLESHOOTING (TO BE PERFORMED BY STORE PERSONNEL ONLY) ...………………......
TROUBLESHOOTING (TO BE PERFORMED BY TRAINED SERVICE PROVIDERS ONLY) ……….
SERIAL LABEL INFORMATION & LOCATION ..…………………………….……...…....……………..…
PROGRAMMABLE CONTROLLER INFORMATION ………………………………………………………
TECHNICAL SERVICE CONTACT INFORMATION / WARRANTY INFORMATION ...…...…...….....
2
3
4-5
6
7
8
9
10
11
12
13
14
15
16
17
18
19-20
21-22
23
24
25
