Side 1/22

Before contacting, you must have the following:

Serial no., model no., store no., store address, details (photos, leak locations,

damage, store’s ambient conditions, etc.)

Support: structuralconcepts.com/support

Tech Service/Warranty: 1 (800) 433-9490, EXT. 1

Hours: Monday – Friday, 8am to 8pm EST (Closed holidays)

21-34822 REVEAL REFRIGERATED SELF-SERVICE MANUAL-EN REV B DATE: 10/18/24

Reveal® User Manual

PART NUMBER: 21-34822

Please Note

Your specic model number is located on the

serial label (usually at the case rear). However,

label locations may vary depending on the

model – see page 20 for more details.

Models shown on this cover sheet do not

represent all models covered by this manual.

Models

NE3613RSSV

NE3620RSSV

NE3627RSSV

NE3635RSSV

NE4813RSSV

NE4820RSSV

NE4827RSSV

NE4835RSSV

NE6020RSSV

NE6027RSSV

NE6035RSSV

NE7220RSSV

NE7227RSSV

NE7235RSSV

NR3633RSSV

NR3640RSSV

NR3647RSSV

NR3655RSSV

NR4833RSSV

NR4840RSSV

NR4847RSSV

NR4855RSSV

NR6040RSSV

NR6047RSSV

NR6055RSSV

NR7240RSSV

NR7247RSSV

NR7255RSSV

Reveal® User Manual 2

Overview / Type / Compliance / Warnings / Precautions / Wiring / Plugs .............................................................................. 3-5

Installation: Case Removal From Skid .............................................................................................................................................6-7

Installation: Start Up ..............................................................................................................................................................................8

Placement of Case ................................................................................................................................................................................9

Product Placement .............................................................................................................................................................................. 10

Shelf and Deck Load Limits .................................................................................................................................................................. 11

Front Panel Removal ............................................................................................................................................................................12

Rear Panel Removal .............................................................................................................................................................................13

Cleaning Schedule (To Be Performed by Store Personnel) ........................................................................................................... 14

Preventative Maintenance ............................................................................................................................................................15-19

Serial Label Information & Location ..................................................................................................................................................20

Programmable Controller Information ..............................................................................................................................................21

Technical Service Contact Information / Warranty Information ..................................................................................................22

Table of Contents
