REV F DATE: 06/23/2023
USER MANUALS\21-20981_REVEAL_USER MANUAL_NE(L)(H)HSV_HTD_SVC_SLIDE-IN_CASE
SCC P/N
21-20981
USER
MANUAL
REVEAL® SLIDE-IN HEATED SERVICE MERCHANDISERS
> REAR SLIDING DOORS
> CAUTION! DO NOT PUSH OR PULL ON UPPER GLASS ENCLOSURE!
> ONLY USE HANDLES (AT EACH END OF CASE) TO PUSH OR PULL CASE INTO POSITION!
Reveal
®
READ AND SAVE THESE INSTRUCTIONS
Model NE3627HSV Slide-In Unit Shown With
Dual Shelves (Your Unit May Vary)
Model NE3635HSV Slide-In Unit Shown With
Three Shelves (Your Unit May Vary)
Important! See Structural Concepts Reveal®
Service Counter Guide P/N 21-21126 (That
Accompanies This Manual) For Cabinetry
Construction/Design Requirements.
Structural Concepts Corp. ∙ 888 E. Porter Rd ∙ Muskegon, MI 49441 Phone: 231.798.8888 Fax: 231.798.4960 ∙ www.structuralconcepts.com
2
TABLE OF CONTENTS
TABLE OF CONTENTS …………………………………………………………………………………...…...
REVEAL® FREE STANDING HEATED SERVICE MODEL APPLICABILITY & DIMENSIONS ....…..
REVEAL® SLIDE-IN SERVICE HEATED MODEL APPLICABILITY & DIMENSIONS ....……………..
INSTALLATION: DISCONNECTING CASE FROM PALLET / REMOVAL OF CASE FROM PALLET
INSTALLATION, CONT’D: SHELVING ASSEMBLY COMPONENTS ...………………………………...
INSTALLATION, CONT’D: PLUG IN UNIT / MAIN POWER SWITCH AND LED LIGHT SWITCH ....
INSTALLATION, CONT’D: ATTACHING REAR UPPER PANEL AND WATER FILL FUNNEL ……..
CASE DESIGN: FRONT VIEW OF SLIDE-IN, SERVICE HEATED MERCHANDISERS .....................
CASE DESIGN, CONT’D: REAR VIEW OF SLIDE-IN, SERVICE HEATED MERCHANDISERS ..…..
CASE DESIGN, CONT’D: CONTROLLER / LED DRIVER / LIGHTS SWITCH / MAIN POWER
SWITCH ……………………...….………………………………………………………………………
CASE DESIGN, CONT’D: TUB ACCESS / HEATER / POWERED HUMIDIFICATION SYSTEM
ACCESS .………………………………………………………………………………………………..
CASE DESIGN, CONT’D: POWERED HUMIDIFICATION SYSTEM / WATER CAPACITY/TYPE ……..
CASE DESIGN, CONT’D: POWERED AND PASSIVE HUMIDIFICATION SYSTEM OVERFLOW …...
CASE DESIGN, CONT’D: PASSIVE HUMIDIFICATION SYSTEM / HUMIDITY CONTROL LEVER
AND ADJUSTMENT LEVER KEY ….…………………………………………………………………
CASE DESIGN, CONT’D: LED LIGHTS / LED LIGHTS SWITCH / THERMOMETER ………….....….
CASE DESIGN, CONT’D: REAR SLIDING DOOR REMOVAL / REPLACEMENT ……….……………
CASE STARTUP: HEATER SETTINGS / LIGHTS SWITCH / SHUTTING DOWN CASE / KEY
STORAGE ………………………………………………………………………………………………
PRODUCT PLACEMENT / AIRFLOW CONSIDERATION / LOAD LINES ………………………….…..
CLEANING SCHEDULE (TO BE PERFORMED BY STORE PERSONNEL) ..…....…...…………...….
PREVENTIVE MAINTENANCE (TO BE PERFORMED BY TRAINED SERVICE PROVIDER) ……....
TROUBLESHOOTING (TO BE PERFORMED BY STORE PERSONNEL ONLY) ...………………......
TROUBLESHOOTING (TO BE PERFORMED BY TRAINED SERVICE PROVIDERS ONLY) ……….
SERIAL LABEL INFORMATION & LOCATION ..…………………………….……...…....……………..…
PROGRAMMABLE CONTROLLER INFORMATION……………………………………………………….
TECHNICAL SERVICE CONTACT INFORMATION / WARRANTY INFORMATION ...…...…...….....
