Side 1/21
Rev C Date: 12.02.2019
I:\Manuals\Reveal_Free Standing Dry [Ambient] Self-Service Cases 20-88453.pub
SCC P/N
20-88453
INSTALLATION
& OPERATING
MANUAL
REVEAL® FREE STANDING SELF-SERVICE DRY
(AMBIENT) MERCHANDISERS
> SOLID BACK PANELS OR REAR SLIDING DOORS
> CAUTION! DO NOT PUSH OR PULL ON END PANELS!
> ONLY USE HANDLES (AT EACH END OF CASE) TO
PUSH OR PULL CASE INTO POSITION!
> SEE PAGE 9-10 FOR FRONT PANEL, SIDE CLADDING,
REAR PANEL & TOE-KICK ATTACHMENT GUIDE
Structural Concepts Corporation ∙ 888 E. Porter Road ∙ Muskegon, MI 49441 Phone: 231.798.8888 Fax: 231.798.4960 ∙ www.structuralconcepts.com
Model NR3635DSSV /
Rear Panel / Attached Cladding
Model NR3635DSSV /
Rear Sliding Doors / Attached Cladding
Reveal
®
READ AND SAVE THESE INSTRUCTIONS
Models Are Shipped WITHOUT Panels or
Cladding Attached. See Pages 9 and 10
For Component Attachment Instructions.
Random Model Shown /
Rear Panel / No Attached Cladding
2
TABLE OF CONTENTS
TABLE OF CONTENTS ………………………………………………………………………………….....…...
OVERVIEW / COMPLIANCE / LED LIGHTS PRECAUTION / ELECTRICAL HAZARD WARNING /
WIRING DIAGRAM ……………………………………………………………………..……..………...
REVEAL® FREE STANDING REFRIGERATED SELF-SERVICE MODEL APPLICABILITY AND
INDIVIDUAL MODEL DIMENSIONS ……………...………………………………………….…..…...
INSTALLATION: TOE-KICK & REAR PANEL REMOVAL / REMOVING CASE FROM PALLET .…...
INSTALLATION, CONT’D.: CASTER ADJUSTMENT / LOCK / UNLOCK / CASE REMOVAL
FROM PALLET ……………………………………………………..…………………………..…..…...
INSTALLATION, CONT’D: SHELVING ASSEMBLY COMPONENTS ………………………………..…..
INSTALLATION, CONT’D: FIELD WIRE (OR PLUG IN) CASE / TURN ON LED LIGHTS .……...…….
INSTALLATION, CONT’D: ATTACHING FRONT PANEL COMPONENTS / HANDLES ON SIDES
OF CASE ………………………………………………………………………………………………....
INSTALLATION, CONT’D: ATTACHING SIDE PANELS, REAR UPPER AND LOWER PANEL …..…
INSTALLATION, CONT’D: OPTIONAL ACRYLIC SECURITY COVER .................................................
CASE DESIGN: FRONT VIEW OF FREE STANDING, SELF-SERVICE MERCHANDISERS ...............
CASE DESIGN, CONT’D: REAR VIEW OF FREE STANDING, SELF-SERVICE MERCHANDISERS .
CASE DESIGN, CONT’D: LED LIGHT SWITCH LOCATIONS ………………..…………….………..…...
CASE DESIGN, CONT’D: LED STYLE LIGHT FIXTURES ………………………………………………...
CASE DESIGN, CONT’D: REAR SLIDING DOORS ………….…………….…………….….………..…….
CLEANING SCHEDULE (TO BE PERFORMED BY STORE PERSONNEL) ……………….……..……..
TROUBLESHOOTING (TO BE PERFORMED BY STORE PERSONNEL) ...………………...................
TROUBLESHOOTING (TO BE PERFORMED BY TRAINED SERVICE PROVIDERS ONLY) …..…….
SERIAL LABEL INFORMATION & LOCATION ..…………………………….……...…....……………....…
TECHNICAL SERVICE CONTACT INFORMATION & WARRANTY INFORMATION ...…...…...….......
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
