Side 1/31
REV E DATE: 06/26/2023
USER MANUALS\21-18041_REVEAL_USER MANUAL_NR(L)(H)HSV_HTD_SVC_FREE-STDG_CASE
Model NR4855HSV Free Standing Unit
Shown AFTER Front/Side Cladding and
Toe-Kick Have Been Attached
REVEAL® FREE-STANDING HEATED SERVICE MERCHANDISERS
> REAR SLIDING DOORS
> CAUTION! DO NOT PUSH OR PULL ON UPPER GLASS ENCLOSURE!
> ONLY USE HANDLES (AT EACH END OF CASE) TO PUSH OR PULL CASE INTO POSITION!
> SEE PAGES 10-11 FOR PANEL, GRILLE & TOE-KICK ATTACHMENT INSTRUCTIONS
Model NR4855HSV Free Standing Unit Shown
BEFORE Front/Side Cladding and
Toe-Kick Have Been Attached
SCC P/N
20-18041
User
Manual
Reveal
®
READ AND SAVE THESE INSTRUCTIONS
Structural Concepts Corp. ∙ 888 E. Porter Rd ∙ Muskegon, MI 49441 Phone: 231.798.8888 Fax: 231.798.4960 ∙ www.structuralconcepts.com
2
TABLE OF CONTENTS
TABLE OF CONTENTS …………………………………………………………………………………...…...
REVEAL® FREE STANDING HEATED SERVICE MODEL APPLICABILITY & DIMENSIONS ....…..
OVERVIEW / THERMOMETER / COMPLIANCE / WARNINGS / PRECAUTIONS …….……………...
INSTALLATION: TOE-KICK REMOVAL / DISCONNECTING CASE FROM PALLET ...……..……….
INSTALLATION, CONT’D.: CASTER ADJUSTMENT / LOCK / UNLOCK / CASE REMOVAL
FROM PALLET .………………………………………………………………………………...……...
INSTALLATION, CONT’D: SHELVING ASSEMBLY COMPONENTS ...………………………………...
INSTALLATION, CONT’D: PLUG IN UNIT / TURN ON MAIN POWER SWITCH AND LED LIGHT
SWITCH …………………………………………………………….....……………………………..….
INSTALLATION, CONT’D: ATTACHING FRONT PANEL COMPONENTS …………………....……….
INSTALLATION, CONT’D: ATTACHING SIDE PANELS AND REAR PANEL ………………….……..
CASE DESIGN: FRONT VIEW OF FREE STANDING, SERVICE HEATED MERCHANDISERS …...
CASE DESIGN, CONT’D: REAR VIEW OF FREE STANDING, SERVICE HEATED
MERCHANDISERS …………………………………………………………………………………….
CASE DESIGN, CONT’D: CONTROLLER / LED DRIVER / LIGHTS SWITCH / MAIN POWER
SWITCH ……………………...….………………………………………………………………………
CASE DESIGN, CONT’D: TUB ACCESS / HEATER / POWERED HUMIDIFICATION SYSTEM
ACCESS .………………………………………………………………………………………………..
CASE DESIGN, CONT’D: POWERED HUMIDIFICATION SYSTEM / WATER CAPACITY/TYPE ……..
CASE DESIGN, CONT’D: OVERFLOW SYSTEM (FOR POWERED & PASSIVE HUMIDIFICATION
SYSTEMS) ………………………………………………………………………………………….…...
CASE DESIGN, CONT’D: PASSIVE HUMIDIFICATION SYSTEM / HUMIDITY CONTROL LEVER
AND ADJUSTMENT LEVER KEY ….…………………………………………………………………
CASE DESIGN, CONT’D: LED LIGHT CONNECTION / THERMOMETER FUNCTION &
PLACEMENT ………………………………………………………………………….………….....….
CASE DESIGN, CONT’D: REAR SLIDING DOOR REMOVAL & REPLACEMENT ………...…………
CASE STARTUP / HEATER SETTINGS / LIGHTS SWITCH / SHUTDOWN / PASSIVE
HUMIDIFICATION SYSTEM (OPTIONAL) LEVER KEY STORAGE ..…………………………..
PRODUCT PLACEMENT / AIRFLOW CONSIDERATION / LOAD LINES ………………………….…..
CLEANING SCHEDULE (TO BE PERFORMED BY STORE PERSONNEL) ..…....…...…………...….
PREVENTIVE MAINTENANCE (TO BE PERFORMED BY TRAINED SERVICE PROVIDER) ……....
TROUBLESHOOTING (TO BE PERFORMED BY STORE PERSONNEL ONLY) ...………………......
TROUBLESHOOTING (TO BE PERFORMED BY TRAINED SERVICE PROVIDERS ONLY) ……….
SERIAL LABEL INFORMATION & LOCATION ..…………………………….……...…....……………..…
PROGRAMMABLE CONTROLLER INFORMATION .………………….………………………………….
TECHNICAL SERVICE CONTACT INFORMATION / WARRANTY INFORMATION ...…...…...….....
2
3
4-5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25-26
27-28
29
30
31
