Supermicro X10SLV Bruksanvisning

Supermicro Hovedkort X10SLV

Les nedenfor 📖 manual på norsk for Supermicro X10SLV (103 sider) i kategorien Hovedkort. Denne guiden var nyttig for 23 personer og ble vurdert med 4.4 stjerner i gjennomsnitt av 12 brukere

Last ned PDF

Side 1/103

X10SLV

X10SLV-Q

USER’S MANUAL

Revision 1.0b

Manual Revision 1.0b

Release Date: March 23, 2017

Unless you request and receive written permission from Super Micro Computer, Inc., you may not

copy any part of this document. Information in this document is subject to change without notice.

Other products and companies referred to herein are trademarks or registered trademarks of their

respective companies or mark holders.

Printed in the United States of America

The information in this User’s Manual has been carefully reviewed and is believed to be accurate.

The vendor assumes no responsibility for any inaccuracies that may be contained in this document,

makes no commitment to update or to keep current the information in this manual, or to notify any

person or organization of the updates. Please Note: For the most up-to-date version of this

manual, please see our web site at www.supermicro.com.

Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product

described in this manual at any time and without notice. This product, including software and docu-

mentation, is the property of Supermicro and/or its licensors, and is supplied only under a license.

Any use or reproduction of this product is not allowed, except as expressly permitted by the terms

of said license.

IN NO EVENT WILL SUPER MICRO COMPUTER, INC. BE LIABLE FOR DIRECT, INDIRECT,

SPECIAL, INCIDENTAL, SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE

USE OR INABILITY TO USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF

THE POSSIBILITY OF SUCH DAMAGES. IN PARTICULAR, SUPER MICRO COMPUTER, INC.

SHALL NOT HAVE LIABILITY FOR ANY HARDWARE, SOFTWARE, OR DATA STORED OR USED

WITH THE PRODUCT, INCLUDING THE COSTS OF REPAIRING, REPLACING, INTEGRATING,

INSTALLING OR RECOVERING SUCH HARDWARE, SOFTWARE, OR DATA.

Any disputes arising between manufacturer and customer shall be governed by the laws of Santa

Clara County in the State of California, USA. The State of California, County of Santa Clara shall

be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for all

claims will not exceed the price paid for the hardware product.

FCC Statement: This equipment has been tested and found to comply with the limits for a Class B

digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reason-

able protection against harmful interference in a residential installation. This equipment generates,

uses, and can radiate radio frequency energy and, if not installed and used in accordance with the

manufacturer’s instruction manual, may cause interference with radio communications. However,

there is no guarantee that interference will not occur in a particular installation. If this equipment

does cause harmful interference to radio or television reception, which can be determined by turn-

ing the equipment off and on, you are encouraged to try to correct the interference by one or more

of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and the receiver.

• Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/television technician for help.

California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate warn-

ing applies only to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate

Material-special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate”.

WARNING: Handling of lead solder materials used in this product

may expose you to lead, a chemical known to the State of California

to cause birth defects and other reproductive harm.

Produkspesifikasjoner

Merke:	Supermicro
Kategori:	Hovedkort
Modell:	X10SLV
Bredde:	170 mm
Dybde:	170 mm
Wi-Fi:	Nei
Strømkildetype:	ATX
Antall USB 2.0-porter:	2
Antall HDMI-porter:	1
Antall DisplayPorts:	1
Maksimalt internminne:	16 GB
Trusted Platform Module (TPM):	Ja
Grafikkadapterfamilie:	Intel
Minnespenning:	1.5 V
LAN-kontroller:	Intel I210-AT, Intel I217
Støttede minnetyper:	DDR3-SDRAM
Hovedkort formfaktor:	Mini-ITX
Antall minnespor:	2
BIOS-type:	UEFI
ACPI-versjon:	5.0
USB 2.0-tilkoblinger:	2
Antall COM-porter:	5
Antall mSATA-porter:	1
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	2
Oppbevaringstemperaturomåde (Celsius):	0 - 60 °C
prosessorprodusent:	Intel
Antall DVI-I-porter:	1
Ubufret minne:	Ja
Kompatible prosessorserier:	Intel Celeron, Intel Pentium
Prosessorstøpsel:	LGA 1150 (kontakt H3)
Støttede lagringsgrensesnitt:	SATA II, SATA III
Ethernet/bredbåndsforbindelse:	Ja
Ethernet-grensesnittype:	Gigabit Ethernet
Antall SATA II-tilkoblinger:	2
Antall SATA III-tilkoblinger:	2
BIOS minnestørrelse:	128 Mbit
Støttede minneklokkehastigheter:	1600 MHz
Systemkort kretsoppsett:	Intel® H81
PCI Express x16 (Gen 2.x) slots:	1
Minnesportype:	SO-DIMM
Støttede minnemodulkapasiteter:	1GB, 2GB, 4GB, 8GB
Hovedkort-chipsettfamilie:	Intel
Lyd-utgang kanaler:	7.1 kanaler
Videokontakter:	HD Graphics 4600
Intel® Core i3/i5/i7/i9 series:	i3-4xxx, i5-4xxx, i7-4xxx
Antall USB 3.2 Gen 1 (3.1 Gen 1)Type-A-porter:	2
PC-ytelsesovervåkning:	FAN, LED, Temperature, Voltage
Trusted Platform Module (TPM)-versjon:	1.2
