Side 1/1

Rechargeable Li-ion Battery Pack

Ver:A

Tel:+86-25-85805753

Fax:+86-25-85805296

http://www.swit.cc

E-mail: contact@swit.cc

USER MANUAL

S W I T E l e c t r o n i c s Co. , LT D.

Features

Storage

Caution

Charging and Discharging

1. High performance Li-ion battery pack, rechargeable.

2. 4-step LED power indicator.

3. Build-in multiple protective circuit design.

4. D-tap DC output, to power the camera and other equipment

simultaneously.

5. S-8180A/S support 6A fast charging, by SWIT S-3812A/S fast

charger.

1. Keep the battery pack terminals clean.

2. The battery pack may become warm in use or while being

charged. This is normal.

3. Never expose the battery pack to rain, re or moisture.

4. Never expose the battery pack to temperature above 60°C.

5. Please pay attention to the polarity of the D-tap DC output

6. Please check the max current of the battery plate of the

equipment to avoid damage to battery plate or battery.

IMPORTANT SAFETY INSTRUCTIONS

Never short-circuit the battery pack terminals.

Never attempt to open the battery pack.

Keep the battery pack away from re or hot place.

Avoid strong mechanical shock.

Charging:

1. It is suggested that fully charge the battery before use.

2. Please use SWIT charger to charge.

3. The battery pack should be charged within a temperature

range of 0-40°C.

Discharging:

1. Fully charged battery pack will discharge naturally and please

use it as soon as it gets charged.

2. At low temperature, the running time of battery pack usually

decreases.

3. The internal impedance of battery pack will be greater at low

temperature, which may cause the automatically circuit cutting.

4. The battery will automatically cut o power to protect itself

when voltage, current or temperature is abnormal. Please take

o the battery, and follow the down blow steps to reactivate

the battery:

(1) Under indoor temperature, lay the battery pack aside for 3-5

minutes and mount the battery pack to any SWIT charger, it

will be re- activated and get charging normally.

(2) If the environment temperature is high, please lay the battery

pack aside for 20-30 minutes and then charge the battery by

SWIT chargers to active.

Store the battery pack in cool, dry and clean place.

Specification

Capacity

95Wh

146Wh

220Wh

73Wh

6.6Ah

10.2Ah

15.3Ah

5.1Ah

70W

100W

140W

66W

12A

5.5A

Dimension

134×88×54mm

134×88×52mm

165×90×53mm

165×90×51mm

165×90×68mm

165×90×66mm

185×72×25mm

Model

S-8082A

S-8082S

S-8110A

S-8110S

S-8180A

S-8180S

S-8073N

Mount Type

Gold Mount

V-Mount

Gold Mount

V-Mount

Gold Mount

V-Mount

NP-1

Nominal Voltage

14.4V

Mass

710g

940g

1280g

450g

Max output

Produkspesifikasjoner

Merke:	SWIT
Kategori:	kamerabatteri
Modell:	S-8073N
Vekt:	490 g
Bredde:	185 mm
Dybde:	72 mm
Høyde:	25 mm
Batterikapasitet:	73 Wh
Antall per pakke:	1 stykker
Merkekompatibilitet:	Alle merker
Batteriteknologi:	Lithium-Ion (Li-Ion)
Produktfarge:	Sort
Batterispenning:	14.4 V
Driftstemperatur (T-T):	0 - 40 °C
Formål:	Videocamera
