WIRELESS 433 MHz TEMPERATURE STATION
Instruction Manual
INTRODUCTION:
Congratulations on purchasing this revolutionary 433MHz temperature Station which provides advanced
data-logging and data-analysis functions for up to three outdoor temperature readings. The temperature
station is connectable to PC by the COM port and data importing to PC is allowed. By applying the smart
software provided, user may perform data analysis and statistics conveniently in PC. With easy to use
keys, this innovative product is ideal for home and professional usages.
FEATURES:
The Temperature Station
Function keys
LCD screen
Hanging Hole
Battery
Compartment
Foldout stand
Cable socket (to PC)
44
DCF radio controlled time with manual setting option
Time zone option ±12 hours
Indoor and outdoor temperature display with MIN/MAX records and time of reception
Indoor and outdoor humidity display as RH% with MIN/MAX records
Data logging function – can store up to 3000 sets of Temperature/Humidity data
Connectable to PC (Com port) – data can be transferred to PC with the software (in CD ROM)
provided
Can receive up to 3 outdoor transmitters
Time reception ON/OFF selectable
Dew point temperature displayed
Temperature & humidity High/Low alarm function
12/24 hour time display
Year/ Month/ Day calendar display
Temperature display in ºC/ ºF
LCD contrast selectable
Low battery indicator
Table standing or wall mounting
The Outdoor Temperature Transmitter
Remote transmission of outdoor temperature and
humidity to Temperature Station by 433 MHz
Shower proof casing
Wall mounting case
Mounting at a sheltered place. Avoid direct rain and
sunshine
45
HOW TO INSTALL AND REPLACE BATTERIES IN THE TEMPERATURE STATION
The Temperature Station uses 3 x AA, IEC LR6, 1.5V batteries. To install and replace the batteries, please
follow the steps below:
1. Insert finger or other solid object in the space at the bottom
center of the battery compartment and lift up to remove the
cover.
2. Insert batteries observing the correct polarity (see
3. Replace compartment cover.
marking).
HOW TO INSTALL AND REPLA E BATTERIES IN THE TEMPERATURE
and replace the
g the correct
ery compartment
SIZE AA LR6
SIZE AA LR6
SIZE AA LR6
C
TRANSMITTER
The Outdoor Temperature transmitter uses 2 x AAA. IEC LR03, 1.5V batteries. To install
batteries, please follow the steps below:
1. Remove the battery cover
Batt
2. Insert the batteries, observin
polarity (see battery compartment marking)
3. Replace the battery cover on the unit
46
