User's Manual

Benutzerhandbuch

Mode d’emploi

Manual del usuario

Manuale dell’utente

Manual do Utilizador

明書

用戶手冊ユーザーズマニュアル

Руководство пользователя

kullan c elkitabı ı ı

(EEE Yönetmeli ine Uygundur)ğ

คู่มือการใช้

ure is for reference only

Div TG Air

Join Tt Community To Receive Benefits

Tt LCS-Liquid Cooling Support Certification

TT Premium

Dear Valued Customer,

Thank you for choosing Thermaltake.

As a new user we value your thoughts and opinions and

your feedback is important to us. We at Thermaltake

would like to use this opportunity to invite you to join our

Community Forums. Register today to start enjoying the

full benefits of our community.

Benefits of being a member:

Quick and responsive user support

Receive help and advice with new builds

Keep up to date with new product releases

Share your thoughts and builds with the community

Enter monthly contests and giveaways

Tt LCS Certified is a Thermaltake exclusive certification

applied to only products that pass the design and

hardcore enthusiasts standards that a true LCS chassis

should be held to. The Tt LCS certification was created

so that we at Thermaltake can designate to all power

users which chassis have been tested to be best

compatible with extreme liquid cooling configurations to

ensure you get the best performance from the best

features and fitment.

Brand official website

http://www.thermaltake.com/

Global Facebook

https://www.facebook.com/ThermaltakeInc

TT Premium

To continue achieving the corporate mission of delivering the

perfect user experience, Thermaltake developed “TT Premium”

with the essence of combining supreme quality products with a

new logo design. TT Premium is far more than just a guarantee

of quality. Behind the name, it represents the passion in DIY,

Modding and Thermaltake’s desire to be the most innovative

brand in the PC hardware market. To satisfy the demand of the

high-end PC users, TT Premium follows its core values of

Excellent Quality, Unique Design, Diverse Combinations and

Boundless Creativity to provide a high performance PC product

for every enthusiast. http://ttpremium.com

Taiwan Facebook

http://www.facebook.com/ThermaltakeTW

Global community forums

http://community.thermaltake.com

Chapter 1. Product Introduction

Specification

Accessory

Warning and Notice

1.0

1.1

1.2

Contents

Chapter 2. Installation Guide

2.0

2.1

2.2

2.3

2.4

2.5

2.6

2.7

2.8

Remove Components

Power Supply Unit (PSU) Installation

Motherboard Inst allation

3.5" & 2 .5" HDD Installation

PCI Card Installatio n

Air Cooling Installa tion

AIO Liquid Cooling Installation

I/O Connection

Remove Filters

Specification

01 02

Mid Tower

Radiator Support

Front: 1 x 360mm, 1 x 240mm, 1 x 120mm

1 x 280mm, 1 x 140mm

Right (M/B Side): 1 x 240mm, 1 x 120 mm

Rear: 1 x 120mm

Case Type

Dimension (H*W*D) 475 x 220 x 461 mm (18.7 8.7 x 18.1 inch)x

Cooling System

Fan Support

Clearance

Front: 3 x 120 mm, 2 x 120 mm, 1 x 120 mm

2 x 140mm, 1 x 140mm

Top: 1 x 120 mm, 1 x 140 mm

Right (M/B Side): 2 x 120 mm, 1 x 120 mm

Rear: 1 x 120 mm

Drive Bays

2 x 3.5”, 5 x 2.5”

or 7 x 2.5”

Expansion Slots

7 Rotatable Patented Design)(

Motherboards

6.7” x 6.7” (Mini ITX), 9.6” x 9.6” (Micro ATX), 12” x 9.6” (ATX)

I/O Port

USB 3.2 (Gen 2) Type-C x 1, USB 3.0 x 2, HD Audio x 1

Side Panel

Tempered Glass x 1

CPU cooler height limitation: 145 mm

VGA length limitation: 360 mm With radiator)(

390 mm Without radiator)(

PSU length limitation: 180 mm With HDD Cage)(

mm(Without HDD Cage)220

Model

Divider 300 TG Air Divider 300 TG Air Snow

Material

SPCC

Front (intake) :

120 x 120 x 25 mm Standard fan

(1000rpm, 16 dBA) x 1

Rear (exhaust) :

120 x 120 x 25 mm Standard fan

(1000rpm, 16 dBA) x 1

PSU

Standard PS2 PSU (optional)

For Motherboard / 2.5” HDD / SSD

For PSU

For Case Fan

Backup

Figure Use For

Q ty`

Cable Management

Stand off #6 32 x 6.5 mm- -

Net setter

Screw #6-32 x 6 mm

Part Name

Screw M3 x 5 mm

Screw #6-32 x 6 mm

Cable Ties

Buzzer

Rubber 10 x 4 mm

For PSU

Motherboard Alarm

For Motherboard Stand off-

For 3.5” HDD / VGA bracket

Screw 5 x 10 mm 4

VGA Bracket

Backup

Thumb Screw #6-32 x 5 mm

Backup

Accessory

Divider 300 TG Air Divider 300 TG Air

Color

Black White

Produkspesifikasjoner

Merke:	Thermaltake
Kategori:	Computerbehuizing
Modell:	Divider 300 TG Air
Vekt:	8180 g
Bredde:	220 mm
Dybde:	461 mm
Høyde:	475 mm
Lydutgang:	Ja
Materiale:	SPCC
Støttede HDD-størrelser:	- "
Antall utvidelsesspor:	7
Produktfarge:	Sort
Formfaktor:	Midi Tower
Modell/Type:	PC
Krav til strømforsyning:	- W
Støttet systemdisk formfaktorer:	ATX, Micro ATX, Mini-ITX
Antall USB 3.2 Gen 1 (3.1 Gen 1)Type-A-porter:	2
Lydkontakter:	Ja
Antall 3.5" bays:	2
Antall 2.5" bays:	7
Siderute:	Ja
Maksimal høyde CPU-kjøler:	145 mm
Maksimal lengde grafikkort:	390 mm
Maksimal lengde PSU:	220 mm
Frontvifte installert:	1x 120 mm
Maksimale frontvifter:	3
Frontviftediameter som støttes:	120,140 mm
Antall bakvifter som støttes (maks.):	1
Bakre viftediametere som støttes:	120 mm
Antall toppvifter som støttes (maks.):	1
Toppviftediametere som støttes:	120,140 mm
Støttede radiatorstørrelser foran:	120,140,240,280,360 mm
Støttede radiatorstørrelser bak:	120 mm
Bakre vifter installert:	1x 120 mm
Antall sidevifter som støttes (maks.):	2
Sideviftediametere som støttes:	120 mm
Antall USB 3.2 Gen 2 (3.1 Gen 2)Type-C-porter:	1
