SG09

Installation and system optimization guide:

The following manual and guides were carefully prepared by the SilverStone engineering team to help

you maximize the potential of your SilverStone product. Please keep this manual for future reference

when upgrading or performing maintenance on your system. A copy of this manual can also be

downloaded from our website at:

http://www.silverstonetek.com

Disassemble chart

Connector definition

Front I/O connector guide

Component size limitations

Recommended cooling device setup & selection

Installation guide

Specification

P. 2

P. 3

P. 5

P.17

P.19

P.20

P.27

Protect your computer

P.49

Upgrade and Maintenance

P.39

Q&A

P.50

SUGO SG09

Redefining performance in small form factor computing

Material

Model

Motherboard

Drive Bay

Cooling System

Expansion Slot

Front I/O Port

Power Supply

Expansion Card

Dimension

Extra

*If you intend to utilize all hard drive slots, please remove all unused power supply cables. These unused

cables may cause problem with the installation. SSDs are highly recommended in place of hard drives.

*Maximum length for PSU is 180mm, we recommend 160mm due to varying connector locations on PSUs

and the unique structure of SG09. We do not promise that all retail PSUs on the market can be installed in

the SG09. Please refer the guides provided in this manual to select your PSU.

Plastic front panel and steel body

SST-SG09B (Black)

Micro ATX, Mini-DTX, Mini-ITX

Exposed

Internal

Rear

Top

Left

Right

USB 3.0 x 2 (backwards compatible with USB 2.0)

audio x 1, MIC x 1

Optional standard PS2 (ATX) up to 180mm*

Compatible up to 13.3” long

220mm (W) x 295mm (H) x 354mm (D), 23.0 liters

support two Kensington locks

12.7mm/9.5mm slim optical drive x 1

3.5" x 2 *, 2.5" x 4*

1 x 120mm 1200rpm 22dBA

180mm Air Penetrator 700/1200rpm, 18/34dBA

(backward compatible with 140mm)

1 x 120mm 1200rpm 22dBA (backward compatible with 92mm)

2 x 80/92mm fan slot

80mm fan slot

Produkspesifikasjoner

Merke:	SilverStone
Kategori:	Computerbehuizing
Modell:	SG09
Vekt:	5300 g
Bredde:	220 mm
Dybde:	354 mm
Høyde:	295 mm
Innebygde høyttalere:	Nei
Lydutgang:	Ja
Materiale:	Plastic, Steel
Støttede HDD-størrelser:	2.5, 3.5 "
Antall utvidelsesspor:	4
Viftehastighet:	1200 RPM
Produktfarge:	Sort
Formfaktor:	Cube
tilbakestillingsknapp:	Ja
Modell/Type:	PC
Av/på-bryter:	Ja
Støttet systemdisk formfaktorer:	DTX, Micro ATX, Mini-ITX
Antall USB 3.2 Gen 1 (3.1 Gen 1)Type-A-porter:	2
Lydkontakter:	Ja
Strømforsyning medfølger:	Nei
Viftediameter:	180 mm
Antall 3.5" bays:	2
Antall 2.5" bays:	4
Siderute:	Nei
Maksimal høyde CPU-kjøler:	165 mm
Maksimal lengde PSU:	180 mm
Antall bakvifter som støttes (maks.):	1
Bakre viftediametere som støttes:	120 mm
Antall toppvifter som støttes (maks.):	1
Toppviftediametere som støttes:	140,180 mm
Bakre vifter installert:	1x 120 mm
Antall interne 3,5" brønner:	2
Antall sidevifter som støttes (maks.):	4
Sideviftediametere som støttes:	80, 92, 120 mm
Strømforsyningens plassering:	Topp
Installerte toppvifter:	1x 180 mm
Installerte sidevifter:	1x 120 mm
