Side 1/32
RVZ02
1
Installation and system optimization guide:
The following manual and guides were carefully prepared by the RAVEN engineering team to help
you maximize the potential of your SilverStone product. Please keep this manual for future reference
when upgrading or performing maintenance on your system. A copy of this manual can also be
downloaded from our website at:
http://www.silverstonetek.com
Specifications
Disassemble Chart
Installation Guide
Connector definition
Component Size Iimitations
Optimal Thermal Performance Layout
Filter removal
Protect Your Computer
Q & A
P. 2
P. 3
P. 5
P.12
P.15
P.21
P.24
P.25
P.26
RVZ02
The perfect slim case for
gaming and multimedia
2
Specifications
Material
Model
Motherboard
Drive Bay
Cooling System
Expansion Slot
Front I/O Port
Power Supply
Expansion Card
Limitation of CPU cooler
Dimension
Extra
*Expansion card holder needs to be removed when installing expansion/graphics card wider than 4.78 inches.
When system is assembled without the holder, vertical orientation of the case is recommended and transporting/shipping should be avoided.
For more details, please refer to manual.
Reinforced plastic outer shell, steel body
SST-RVZ02B (black)
SST-RVZ02B-W (black + window)
Mini-ITX
External
Internal
Sides
Rear
2
USB 3.0 x 2, Audio x 1, MIC x 1
SFX & SFX-L
*Compatible with 13” long, width restriction – 4.78”
58mm
380mm (W) x 87mm (H) x 370mm (D), 12 liters
Support two Kensington locks
Slim slot-loading optical 12.7mm or 9.5mm x 1
(9.5mm compatibility limited to tray type)
2.5” x 2
(one additional 3.5” or 2.5” space depending on expansion card installed)
Oversized vents over CPU/motherboard and expansion area
Passive exhaust vents
Redefine expectations
