Side 1/28

Primera Series

PM01

Pioneering computer case with exceptional style and functionality

The following manual and guides were carefully prepared by the SilverStone engineering team to

help you maximize the potential of your SilverStone product. Please keep this manual for future

reference when upgrading or performing maintenance on your system. A copy of this manual can also

be downloaded from our website at:

Warranty Information

Installation and system optimization guide:

Product Overview

Specification

Disassemble Chart

Installation Chart

Top Cover Removed Guide

Connector Definition

Componet Size Limitations

Upqrade And Mainterance

P.1

P.2

P.4

P.14

P.15

P.18

P.22

Product Overview

Primera Series PM01

Specifications

Primera is the Spanish word for “first” or “first class.” Cases in

this series are designed for those seeking to build PCs with rich

feature set and trend-setting aesthetics.

The Primera PM01 is an incredible computer case that fuses

eye-catching styling and functionality in a package rarely seen in the

PC world. It utilizes high quality, piano-like finish with oversized

intake mesh panel inspired by sports car intake grill for unusually

sleek exterior. Paired with an elaborate lighting system consists of

LED fans and built-in adjustable LED strips, the PM01 can project

the feel of a luxurious supercar on a highly customizable computer

case. The roomy interior layout supports a variety of large, high end

components that are designed to be cooled efficiently and quietly

by the included three 140mm LED intake fans and an 140mm exhaust

fan. True to SilverStone tradition, the PM01 also has excellent dust

protection thanks to implementation of easily removable filters and

positive pressure airflow setup. Novice users will find this case a

pleasure to build with and maintain while advanced users will find

details such as support for two 360mm radiator mounting positions

and water tank mounting holes to be highly useful for building beautiful

liquid cooled PCs.

Model No.

Material

Motherboard

Drive Bay

Cooling System

Radiator Support

Expansion Slot

Front I/O Port

Power Supply

Expansion Card

Limitation of CPU cooler

Limitation of PSU

Dimension

SST-PM01BR-W (black with red LED + window)

SST-PM01CR-W (matte black with red LED + window)

SST-PM01WA-W (white with blue LED + window)

Plastic outer shell steel body

ATX (up to 12" x 10.7"), Micro ATX

External

Internal

Front

Rear

Top

Front

Rear

Top

USB 2.0 x 2, USB 3.0 x 2, Audio x 1, MIC x 1

Standard PS2 (ATX)

Support graphics card up to 16.5", width restriction - 6.88"

180mm

240mm

220mm (W) x 571mm (H) x 560mm (D), 70.3 liters

None

2.5" or 3.5" x 4, 2.5" x 5

3 x 120mm / 140mm fan slot (includes 3 x 140mm LED fan)

1 x 120mm / 140mm fan slot (includes 1 x 140mm fan)

3 x 120mm fan slot or 2 x 140mm fan slot

240mm / 280mm / 360mm x 1

120mm / 140mm x 1

Introduction

Cases in

with rich

at fuse

en in the

versi

zed

nusuall

nsists of

oje

omputer

h end

d quietl

exhaust

llent d

ust

lters and

s case a

will find

positions

beautiful

Produkspesifikasjoner

Merke:	SilverStone
Kategori:	Computerbehuizing
Modell:	Primera PM01
Vekt:	9000 g
Bredde:	220 mm
Dybde:	560 mm
Høyde:	571 mm
LED-indikatorer:	Ja
Bruksanvisning:	Ja
Antall USB 2.0-porter:	2
Lydutgang:	Ja
Materiale:	Plastic, Steel
Støttede HDD-størrelser:	2.5, 3.5 "
Antall utvidelsesspor:	7
Volum:	70.3 l
Produktfarge:	Sort
Formfaktor:	Midi Tower
Modell/Type:	PC
Belysning:	Ja
Belysningsfarge:	Rød
Støttet systemdisk formfaktorer:	ATX, Micro ATX
Antall USB 3.2 Gen 1 (3.1 Gen 1)Type-A-porter:	2
Lydkontakter:	Ja
Strømforsyning medfølger:	Nei
Antall 3.5" bays:	4
Antall 2.5" bays:	5
Siderute:	Ja
Belysningsområde:	PC-kabinettvifte
Maksimal høyde CPU-kjøler:	180 mm
Maksimal lengde grafikkort:	419 mm
Maksimal lengde PSU:	240 mm
Støttede formfaktorer strømforsyning:	ATX
Frontvifte installert:	3x 140 mm
Maksimale frontvifter:	3
Frontviftediameter som støttes:	120,140 mm
Antall bakvifter som støttes (maks.):	1
Bakre viftediametere som støttes:	120,140 mm
Antall toppvifter som støttes (maks.):	3
Toppviftediametere som støttes:	120,140 mm
Støttede radiatorstørrelser foran:	240,280,360 mm
Støttede radiatorstørrelser bak:	120,140 mm
Støttede radiatorstørrelser øverst:	120,240,280,360 mm
Bakre vifter installert:	1x 140 mm
Antistøvfilter:	Ja
Strømforsyningens plassering:	Bunn
