SilverStone Grandia GD09 Bruksanvisning

SilverStone Computerbehuizing Grandia GD09

Les nedenfor 📖 manual på norsk for SilverStone Grandia GD09 (36 sider) i kategorien Computerbehuizing. Denne guiden var nyttig for 4 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere

Last ned PDF

Side 1/36

GD09

Product Overview

Installation and system optimization guide:

The following manual and guides were carefully prepared by the SilverStone

engineering team to help you maximize the potential of your SilverStone product.

Please keep this manual for future reference when upgrading or performing

maintenance on your system. A copy of this manual can also be downloaded from

our website at:

www.silverstonetek.com

Specification

Disassemble Chart

Installation Guide

Connector Definition

Componet Size Limitations

Recommended Cooling Device Setup And Selection

Upgrade And Maintenance

P. 1

P. 2

P. 3

P.15

P.18

P.25

P.28

Protect Your Computer

P. 32

Q&A

P. 33

Warranty Information

The perfect HTPC case for everyone

Material

Model

Motherboard

Drive Bay

Cooling System

Expansion Slot

Front I/O Port

Power Supply

Expansion Card

Limitation of CPU cooler

Dimension

Plastic front panel with faux aluminum finish, 0.8mm steel body

SST-GD09B (black)

SSI CEB, ATX, Micro ATX*

Exposed

Internal

Right

Rear

Top

Left

7 + 1

USB 3.0 x 2, audio x 1, MIC x 1

Standard PS2 (ATX)

220mm maximum, 180mm recommended

Support cards up to 12.2”, width restriction 5.25”

138mm

440mm (W) x 170mm (H) x 358mm (D), 26.8 liters

5.25" x 1 (compatible with 3.5” x 1 or 2.5” x 2)

3.5" x 2 (one compatible with 2.5”), 2.5” x1

1 x 120mm intake fan, 900rpm, 18dBA

1 x 120mm fan slot

2 x 80mm fan slot

Expansion card vent

1 x 120mm fan slot, compatible with 80mm fan

Product Overview

Specification

Introduction

The Grandia GD09 is a culmination of SilverStone’s decade-long experience in HTPC case design and manufacturing into a product

that every PC enthusiast can enjoy. The incredible efficiency in which it utilizes all available space results in a case that is close in

size externally to Micro-ATX based GD04 and GD05, yet capable of fitting most important full size standard components including

wider ATX motherboards (SSI-CEB) such as ROG or other gaming-centric models. All drive cages have been designed similarly to

those from the popular ML03 case to provide maximum flexibility in drive configuration without the need for additional adapters. For

cooling, all positive pressure and smooth airflow designs were retained from previous Grandia models while improvements were made

to filter access for even easier maintenance. With the GD09, there has never been a more attractively sized HTPC case that is as

capable and user-friendly. So whether one is looking to build an affordable or a powerful PC, this case can definitely satisfy both

ends of the requirement.

Produkspesifikasjoner

Merke:	SilverStone
Kategori:	Computerbehuizing
Modell:	Grandia GD09
Vekt:	4200 g
Bredde:	440 mm
Dybde:	358 mm
Høyde:	170 mm
Innebygde høyttalere:	Nei
Lydutgang:	Ja
Materiale:	Aluminium, Plastic, Steel
Støttede HDD-størrelser:	3.5 "
Produktfarge:	Sort
Harmonisert system (HS)-kode:	84733080
Formfaktor:	Desktop
Modell/Type:	PC
Støttet systemdisk formfaktorer:	ATX, Micro ATX
Antall USB 3.2 Gen 1 (3.1 Gen 1)Type-A-porter:	2
Lydkontakter:	Ja
Strømforsyning medfølger:	Nei
Siderute:	Nei
Bakre vifter installert:	2x 80 mm
Antall 5.25" bays:	1
Antall interne 3,5" brønner:	2
Installerte sidevifter:	2x 120 mm
