SG08-LITE
The ultimate evolution of high performance Mini-ITX
For years, SilverStone Sugo series has been the benchmark and the standard for high-performance
Mini-ITX chassis. The SG08-LITE was designed to retain all the signature features from the award-winning
SG08 such as the compact 14.8-liter design that can accommodate graphic card up to 12.2” and the premium
10mm aluminum front panel where SilverStone engineers have further updated the slim optical slot into
slot-loading variety for cleaner styling. Its specially designed fan bracket offers the users flexible cooling
options for 180mm fan or 120mm/140mm fan with water-cooling radiator. To keep dust out, all intake vents
are equipped with removable filters for easy-cleaning. In contrast with its relatively small size, the SG08-LITE
supports standard ATX PSU for greater selections and when used with SilverStone’s Strider Gold S series,
the smallest full modular power supplies with 80 PLUS Gold in the world, or our carefully engineered
SFX PSUs, the SG08-LITE can help you create an incredible Mini-ITX system.
SST-SG08B-LITE (black)
【FRONT】【BACK】
2
Extruded aluminum front panel, steel body USB 3.0 x 2 / audio x 1 / MIC x 1
Support standard ATX PSU up
to 160mm in length
Support expansion cards up to
12.2” long, width 4.84”*
222 mm (W) x 190 mm (H) x 351 mm
(D), 14.8 liters
Slim slot-loading optical x 1
3.5" x 1 , 2.5” x 2
120mm/140mm/180mm fan slot
Oversized vents
* To support graphics card longer than 7.25”, a non-modular PSU with maximum 140mm length is required.
VGA exhaust divider
Mini-DTX, Mini-ITX
SG08-LITE
TOP COVER
FAN BRACKET
FAN FILTER
PICTURE ITEM
SCREW A M2 X 2
SCREW B M3 X 4 Secure 2.5" SSD/HDD
Secure optical drive
Secure motherboard
Secure 3.5" SSD/HDD
SCREW C 632 X 6
SCREW D 632 X 10
WIRE - MOUNT
INSTALLATION GUIDE
PURPOSE
ATX PSU (OPTION)
MINI - ITX (OPTION)
EXPANSION
SLOT X 2
PSU FILTER
POWER LED & HDD LED
POWER BUTTON
USB 3.0 + SPK + MIC
SLIM SLOT - LOADING
OPTICAL DRIVE (OPTION)
2.5”HDD X 2
3.5” HDD X 1
HDD CAGE
Disassemble chart
