Side 1/35

December, 2010

Issue date:

G11213300

MANUAL

FORTRESS SERIES

FT03

Installation and system optimization guide:

The following manual and guides were carefully prepared by the SilverStone engineering team to help

you maximize the potential of your SilverStone product. Please keep this manual for future reference

when upgrading or performing maintenance on your system. A copy of this manual can also be

downloaded from our website at:

http://www.silverstonetek.com

Disassemble chart

Connector definition

Front I/O connector guide

Component size limitations

Recommended cooling device setup & selection

Upgrade and Maintenance

Installation guide

Specification

P. 2

P. 3

P. 5

P. 17

P. 19

P. 20

P. 25

P. 28

Q & A

P. 31

Aluminum outer shell, steel body

Micro ATX, Mini-DTX, Mini-ITX

Bottom

Top

SST-FT03B (black)

SST-FT03S (silver)

1 x 120mm exhaust fan, 1200rpm, 22dBA,

1 x 92 / 80mm optional fan

USB 3.0 x 2 (backwards compatible with USB 2.0)

audio x 1, MIC x 1

Standard PS2 (ATX) up to 180mm (160mm for modular cables) deep

Compatible up to 13.77” long

235mm (W) x 487mm (H) x 284mm (D)

Model No.

Expansion Card

3.5" x 3, 2.5” x1

2 x 120mm intake fans, 1200rpm 22dBA,

2 x 80mm optional fan slots

Slot loading slim optical drive x 1

Internal

Aluminum side panel heat conductionHard drive

Exposed

FORTRESS SERIES FT03

The new paradigm for desktop computers

Produkspesifikasjoner

Merke:	SilverStone
Kategori:	Computerbehuizing
Modell:	SST-FT03S
Vekt:	6700 g
Bredde:	235 mm
Dybde:	284 mm
Høyde:	487 mm
Lydutgang:	Ja
Materiale:	Aluminium, Stainless steel
Produktfarge:	Sølv
Type strømforsyning:	PS2
Innebygd kortleser:	Nei
Fjernkontroll medfølger:	Nei
Formfaktor:	Midi Tower
Modell/Type:	PC
Av/på-bryter:	Ja
Støttet systemdisk formfaktorer:	Micro ATX, Mini-DTX, Mini-ITX
Ventilasjonsvifte:	3x 120mm
Interne driverporter:	3x 3.5", 1x 2.5"
Antall USB 3.2 Gen 1 (3.1 Gen 1)Type-A-porter:	2
Lydkontakter:	Ja
Eksterne driverporter:	1
Akustisk trykkemisjon:	22 dB
Valgfri vifte:	1x 92/80mm, 2x 80mm
