Step 1: Connect Power
F-16SDI-3G-TX/RX
Quick Setup Guide
https://thorbroadcast.com sales@thorfiber.com
Connect Included Power Cables to both Transmitter (TX) and Receiver (RX)
800-521-8467
Step 2: Connect Fiber
Connect Transmitter to
Receiver using Single
Mode Fiber with ST/PC
connector (Not Included)
Distance up to 10km
F-16SDI-3G-TX/RX
Quick Setup Guide
800-521-8467https://thorbroadcast.com sales@thorfiber.com
Scan for more info:
Step 3: Connect Inputs/Outputs
Connect SDI video inputs to the
Transmitter and outputs from the
Receiver and loops to the monitors
IN1
Transmitter Inputs SDI 1-16
correspond to Receiver Outputs SDI 1-16
OUT1 IN2 OUT2 IN3 OUT3 IN4 OUT4 IN5 OUT5 IN6 OUT6 IN7 OUT7 IN8 OUT8
OUT9 OUT9 OUT10 OUT10 OUT11 OUT11 OUT12 OUT12 OUT13 OUT13 OUT14 OUT14 OUT15 OUT15 OUT16 OUT16
IN9 OUT9 IN10 OUT10 IN11 OUT11 IN12 OUT12 IN13 OUT13 IN14 OUT14 IN15 OUT15 IN16 OUT16
OUT1 OUT1 OUT2 OUT2 OUT3 OUT3 OUT4 OUT4 OUT5 OUT5 OUT6 OUT6 OUT7 OUT7 OUT8 OUT8
LEDs 1-16 on both TX and RX will light
GREEN when INPUT is properly connected
Signal IN
Signal OUT
Step 4: Loop Outputs (Example)
TX
RX
Signal OUT
Signal OUT
