Side 1/4

SPLASH-PROOF MEGAPHONES ER-1203

ER-1206

ER-1206S

ER-1206W

Thank you for purchasing TOA's Splash-Proof Megaphones.

Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment.

The ER-1203 is a 3 W splash-proof megaphone and the ER-1206 series is a 6 W megaphone.

Both feature IPX5 water-jet-resistant designs.

The ER-1206S offers a siren switch, and the ER-1206W is equipped with a whistle switch.

The use of the supplied battery spacer permits the ER-1206 series to be operated on four AA batteries instead

of six batteries normally required.

Handle and mouthpiece with anti-bacteria treatment improve hygiene and safety during use.

2. GENERAL DESCRIPTION

Water protection: IPX5

INSTRUCTION MANUAL

• Before installation or use, be sure to carefully read all the instructions in this section for correct and safe

operation.

• Be sure to follow all the precautionary instructions in this section, which contain important warnings and/or

cautions regarding safety.

• After reading, keep this manual handy for future reference.

1. SAFETY PRECAUTIONS

• Cautions on Use

Be sure to observe the following instructions. Failing to observe may cause hearing impairment.

· Reduce the volume to its lowest setting before use.

· Never use the megaphone in close proximity to a person's ear.

· Point the megaphone toward the ground when conducting operational tests.

• Make sure to observe the following handling precautions so that a fire or personal injury does not result from

leakage or explosion of the battery.

· Do not short, disassemble, heat nor put the battery into a fire.

· Avoid using both new and old batteries together.

· Never charge batteries of the type which are not rechargeable.

· Do not solder a battery directly.

· Be sure to use the specified type of batteries.

· Note correct polarity (positive and negative orientation) when inserting a battery in the unit.

· Avoid locations exposed to the direct sunlight, high temperature and high humidity when storing batteries.

Indicates a potentially hazardous situation which, if mishandled, could

result in moderate or minor personal injury, and/or property damage.

CAUTION

Traceability Information for Europe (EMC directive 2004/108/EC)

Manufacturer:

TOA Corporation

7-2-1, Minatojima Nakamachi, Chuo-ku, Kobe, Hyogo, Japan

Authorized representative:

TOA Electronics Europe GmbH

Suederstrasse 282, 20537 Hamburg,Germany

4. NOMENCLATURE AND FUNCTIONS

1. Speaker (outer horn)

2. Talk switch

Press to talk (power turns ON). Release to turn

the power OFF.

3. Battery Cover

The battery compartment is built inside. Use care

when opening and closing the battery cover.

4. Mouthpiece

Speak into the mouthpiece at a distance of about

1 cm. Anti-bacteria treated, the mouthpiece helps

make such close contact during use hygienic and

safe.

5. Signal tone switch (ER-1206S/W only)

[ER-1206S]

A siren tone sounds when this switch is pressed,

and stops when pressed again.

[ER-1206W]

A whistle tone sounds while this switch is

pressed, and stops when released.

Note: Output volume is fixed, and cannot be

adjusted with the volume control.

6. Volume control

Rotate right to increase output

volume.

7. Handle

The handle with anti-bacteria treatment improve

hygiene and safety during use.

8. Strap

Use this strap to carry the unit.

(Length: approx. 60 cm)

9. Battery case

Houses AA batteries of 4 pieces for the ER-1203

or 6 pieces (4 pieces when the battery spacer is

used) for the ER-1206 series.

Note: The battery spacer is installed in the

handle (7) by the factory.

Volume high

• The ER-1203/1206/1206S/1206W megaphones are waterproof to IPX5 standard that permits the use of

megaphones in an environment where rain or water may be splashed. Never use them in water or in heavy

rain, nor souse water over them as doing so may cause unit failure.

• Immediately contact your TOA dealer if the following irregularities should occur. To avoid unit failure, make

no further attempt to use the unit in these conditions.

· Smoke coming from the unit or a strange smell detected.

· Water or other foreign objects get inside the unit.

· No sound heard (after checking to be sure that the batteries are loaded in correct orientation, and

satisfactorily charged).

• Avoid storing the unit in humid or dusty locations, in locations exposed to direct sunlight, near heaters, or

exposed to sooty smoke, as these conditions may result in unit failure.

• When batteries are left installed in the megaphone for extended periods of time, be sure to check them

periodically for charge and leakage.

• Do not use the unit for extended periods of time with a distorted sound output. This could cause the inner

parts to become hot and possibly result in unit failure.

• Noise may be produced when a mobile phone is used near the unit. However, this is not a failure. Use the

mobile phone as far as possible from the unit.

• Use a tightly wrung-out damp cloth to clean the unit. If the unit becomes extremely dirty, use a cloth

moistened in a neutral detergent and tightly wrung-out. Never use volatile liquids such as benzene, thinner,

or alcohol to clean the unit, as these may deform or discolor its case.

3. HANDLING PRECAUTIONS

Produkspesifikasjoner

Merke:	Toa
Kategori:	Megafon
Modell:	ER-1203
Vekt:	610 g
Diameter:	137 mm
Strømkildetype:	Batteri
Materiale:	Akrylonitril styren-akrylat (ASA)
Utgangseffekt:	3 W
Lengde:	210 mm
Maksimal rekkevidde:	125 m
Ergonomisk håndtak:	Ja
Driftsspenning:	6 V
Batteritype:	4 x 1, 5 V (AA/R6P)
Produktfarge:	Sort
Antall støttede batterier:	4
