Toa SP-1100 Bruksanvisning
Les nedenfor 📖 manual på norsk for Toa SP-1100 (1 sider) i kategorien Megafon. Denne guiden var nyttig for 2 personer og ble vurdert med 4.7 stjerner i gjennomsnitt av 1.5 brukere
Side 1/1
1
3
2
Inner horn
Holder
SP-1100
Dustproof cover
URL: http://www.toa.jp/
133-03-00009-00
Step 1. Install a self-tapping screw temporarily into the
wall.
Notes
• Use the screw that is appropriate for the
construction of the wall.
• Two 4 x 16 self-tapping screws are supplied
with the SP-1100 bracket.
Step 2. Hook the bracket's slotted hole over the screw
head. Slide the bracket down in the direction
indicated by the arrow.
Step 3. Align the bracket vertically, then fix the bottom part
of the bracket with another self-tapping screw.
Step 4. Tighten both the top and bottom screws to
securely mount the bracket to the wall.
5. INSTALLATION
Two mounting pitches are
made available for selection:
192.5 mm or 242.5 mm.
7. FOLDING THE BRACKET
The holder and dustproof cover can fold if the megaphone
is removed.
Fold the holder first, and then the dustproof cover.
When mounting the megaphone, open the dustproof
cover first, and then the holder.
Step 1. Raise the bracket's dustproof cover.
Step 2. Place the megaphone on the holder with its front
down.
Step 3. Lower the dustproof cover of the bracket.
6. MOUNTING THE MEGAPHONE
When detaching the megaphone from the bracket,
reverse the above procedures.
Note: Lift the megaphone to detach. The dustproof
cover opens if the megaphone is lifted.
1
2
Holder
SP-1100
Dustproof cover
Wall
242.5 mm
192.5 mm
4 x 16 self-tappimg screws (supplied)
Stay
1
2
3
(mm)
Slotted hole dimensions
5
ø10
10
4. SPECIFICATIONS
3.
NOMENCLATURE AND DIMENSIONAL DIAGRAM
INSTRUCTION MANUAL
WALL MOUNTING BRACKET
SP-1100
Thank you for purchasing TOA's Wall Mounting Bracket.
Please carefully follow the instructions in this manual to
ensure long, trouble-free use of your equipment.
420
333
33
126
156
282
77
Dustproof cover
Stay
Slotted hole
Holder
]ediS[]tnorF[
[Megaphone mounted view]
SP-1100
Megaphone
Unit: mm
Wall
Note: The s n d s f t s e s ct tode ig an peci ica ion ar ubje
change without notice for improvement.
• Accessories
4 x 16 tapping screws ................................ 2
•Before installation or use, be sure to carefully read all
the t t s in t s t n for t d safeins ruc ion hi sec io correc an
operation.
•Be s e to f w l the c t y s inur ollo al pre au ionar in ru ionst ct
t s se , ch c t n t t s /orhi ction whi on ai impor an warning and
cautions regarding safety.
•After , p t s l y for futurereading kee hi manua hand
reference.
1. SAFETY PRECAUTIONS
WARNING
Indicates a potentially hazardous situation which,
if s , d s t in th or s usmi handled coul re ul dea erio
personal injury.
•In l the t y in a t n t t n st t lystal uni onl loca io ha ca ruc ural
support the weight of the unit and the mounting bracket.
Doing otherwise may result in the unit falling down and
causing personal injury and/or property damage.
•Avoid t g the ket in t s e lemoun in brac loca ion wher peop
could accidentally bump into it. Failure to observe this
could result in personal injury.
CAUTION
Indicates a potentially hazardous situation which,
if mishandled, could result in moderate or minor
personal injury, and/or property damage.
•Since the unit is designed for indoor use, do not install it
ou doors ins alle ou doors agin part . If t d t , the g of ts
c s the t to f l o , t g in s l y.ause uni al ff resul in per ona injur
A , n it ts t th , t e is a r oflso whe ge we wi rain her dange
electric shock.
•Use the cif d e in t . ngspe ie megaphon combina ion Doi
otherwise may cause the unit or component to fall off,
resulting in personal injury.
•Do not stand or sit on, nor hang down from the unit as
t s y c se it to f l n or , t g inhi ma au al dow drop resul in
personal injury and/or property damage.
2. GENERAL DESCRIPTION
The SP-1100 bracket is designed to be used exclusively
to mount the ER-1203 and ER-1206 series megaphones
on a . It ts the e to be t d inwall permi megaphon ins alle
easy-to-see locations, and the megaphone can be easily
mounted and detached. The dustproof cover protects the
megaphone's mouthpiece while the megaphone is placed
in the bracket, offering improved hygienic safety.
Finish Stay: Stainless steel (SUS304)
Holder, dustproof cover: ASA resin,
dark gray clear
Dimensions [With dustproof cover and holder open]
126 (w) x 420 (h) x 156 (d) mm
Weight 410 g
Usable ER-1203,
Megaphone ER-1206, ER-1206S, ER-1206W
