INSTALLATION MANUAL

SPEAKER RIGGING FRAMES HY-PF7B

HY-PF7W

Thank you for purchasing TOA’s Speaker Rigging Frame.

Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment.

1. SAFETY PRECAUTIONS

• Beforeinstallationoruse,besuretocarefullyread

all the instructions in this section for correct and

safe operation.

• Besuretofollowalltheprecautionaryinstructions

in this section, which contain important warnings

and/orcautionsregardingsafety.

• After reading, keep this manual handy for future

reference.

• Referallinstallationworktothedealerfromwhom

the speaker was purchased. Installation for ying

requires extensive technical knowledge and

experience. The speaker may fall off if incorrectly

installed,resultinginpossiblepersonalinjury.

• FlyingPrecautions

 Besuretofollowtheinstructionsbelow.Otherwise,

the suspension wires or belts may be off or snap

and the speaker may fall off, causing personal

injury.

· Check to conrm that the suspension wires and

beltsarestrongenoughtowithstandthespeaker

load.

· Theconnectorsofthesuspensionwiresandbelts

mustbesecurelylinkedwiththoseofthespeaker.

· All parts and components (such as enclosures,

metalpieces,andscrews)mustbefreefromany

deformation,crack,andcorrosion.

· Besuretousescrewssuppliedwiththeoptional

yinghardwarewheninstallingthespeakerusing

suchhardware.

• Install the speaker only in a location that can

structurallysupporttheweight ofthespeakerand

the mounting bracket. Doing otherwise may result

in the speaker falling down and causing personal

injuryand/orpropertydamage.

• Sincetheframeisdesignedforindooruse,donot

install it outdoors. If installed outdoors, the aging

of parts causes the speaker to fall off, resulting in

personal injury. Also, when it gets wet with rain,

thereisadangerofelectricshock.

• Owing to the speaker’s size and weight, be sure

that at least two persons are available to install the

speaker. Failure to do so could result in personal

injury.

• Donotuseothermethodsthanspeciedtomount

the frame. Extreme force is applied to the frame

andthespeakercouldfalloff,possiblyresultingin

personalinjuries.

• Use nuts and bolts that are appropriate for the

ceiling’sstructureandcomposition.Failuretodoso

may cause the speaker to fall, resulting in material

damageandpossiblepersonalinjury.

• Tighteneachnutandboltsecurely.Ensurethatthe

framehasnoloosejointsafterinstallationtoprevent

accidentsthatcouldresultinpersonalinjury.

• Use the specied speaker in combination. Doing

otherwise may cause the speaker to fall off, resulting

inpersonalinjury.

• Donotmountthespeakerinlocationsexposedto

constantvibration.Theframecanbedamagedby

excessive vibration, potentially causing the speaker

tofall,whichcouldresultinpersonalinjury.

• Avoid installing the speaker in indoor swimming

facilities that are not well ventilated. In such

locations the frame may be vulnerable to corrosion,

eventually allowing the speaker to fall resulting in

personalinjury.

• Avoid touching the frame’s sharp metal edge to

preventinjury.

• Havethe frame checked periodically by the shop

fromwhereitwaspurchased.Failuretodosomay

resultincorrosionordamagetotheframethatcould

cause the speaker to fall, possibly causing personal

injury.

Indicatesapotentiallyhazardoussituationwhich,

if mishandled, could result in death or serious

personalinjury.

WARNING

Indicatesapotentiallyhazardoussituationwhich,

ifmishandled,couldresultinmoderateorminor

personalinjury,and/orpropertydamage.

CAUTION

2. GENERAL DESCRIPTION

The HY-PF7B and HY-PF7W Speaker rigging frames are used exclusively to suspend the HX-7B or HX-7W Speaker

systemfromthehighceilingindoors.

TheFB-150BorFB-150WSubwoofersystemcanalsobesuspendedusingtheHY-PF7BorHY-PF7WandtheSpeaker

riggingframe’ssuppliedmountingbrackets.

EachofHY-PF7BandHY-PF7WiscapableofsuspendinguptotwoHX-7BorHX-7WspeakersandoneFB-150BorFB-

150W.

3. SUSPENDING FB-150B OR FB-150W

• Owing to the speaker’s size and weight, be sure that at least two

persons are available to install the Speaker rigging frame.

 Failuretodosocouldresultinpersonalinjury.

• Tightentheboltssecurely,asinstructedbelow.

 Failuretofollowinstructionspreciselycouldresultinafallingspeaker

andpotentialpersonalinjury.

· Ensurethatallboltsaresecurelyinsertedasfarastheirthreadsgo,

then securely fasten each bolt with a nut.

· Tighten all the bolts with the designated tightening torque. For

tightening,useaPhillipsscrewdriver,oropen-orbox-endwrench.

WARNING

FB-150B or FB-150W

Subwoofer system

Subwoofer fixing bracket (accessory)

Fix the FB-150B or FB-150W.

Attach the fixing brackets at the 4 positions

on the speaker rigging frame.

Hex head bolt M8 x 40

(with plain washer, accessory)

Tightening torque:

8 N·m

Hex head bolt M8 x 40

(with plain washer, accessory)

Tightening torque:

8 N·m

Remove the attached screws.

Note

The removed screws are not used.

Nut for M8 (accessory)

Plain washer for M8

(accessory)

Suspension holes

(4 points)

Turn the rigging frame/Subwoofer assembly upside down,

then suspend it at 4 points on the rigging frame from the

ceiling using chains, wires, or carabiners.

Note: Prepare chains, wires, or carabiners separately.

WhenmountingtheriggingframetotheSubwoofersystem,placetheriggingframeabovetheSubwoofersystemas

shown below.

(Seep.4,"SUSPENSIONEXAMPLES.")
