Side 1/4

1. SAFETY PRECAUTIONS

• Beforeinstallationoruse,besuretocarefullyread

all the instructions in this section for correct and

safeoperation.

• Besuretofollowalltheprecautionaryinstructions

in this section, which contain important warnings

and/orcautionsregardingsafety.

• After reading, keep this manual handy for future

reference.

Indicatesapotentiallyhazardoussituationwhich,

if mishandled, could result in death or serious

personalinjury.

WARNING

• Referallinstallationworktothedealerfromwhom

the speaker was purchased. Installation onto the

ceilingrequiresextensivetechnicalknowledgeand

experience.The speaker may falloff ifincorrectly

installed,resultinginpossiblepersonalinjury.

• Installtheunitonlyinalocationthatcanstructurally

supporttheweightofthespeakerandthemounting

bracket.Doingotherwisemayresultinthespeaker

falling down and causing personal injury and/or

propertydamage.

• Owing to the speaker's size and weight, be sure

thatatleasttwopersonsareavailabletoinstallthe

speaker. Failure todo so could result in personal

injury.

• Donotuseothermethodsthanspeciedtomount

thebracket.Extremeforceisappliedtothebracket

andthespeakercouldfalloff,possiblyresultingin

personalinjuries.

• Usesafetywireswheninstallingspeakers.Ifnot

used, personalinjurycouldresult if a speaker

shouldaccidentallyfall.

• Attachthesafetywiretothespeaker.Ifnotattached,

thespeakercouldfalloff,resultinginpersonalinjury.

• Use nuts and bolts that are appropriate for the

ceiling’sstructureandcomposition.Failuretodoso

maycausethespeakertofall,resultinginmaterial

damageandpossiblepersonalinjury.

• Tighten each nut and bolt securely. Ensure that

the bracket has no loose joints after installation

to prevent accidents that could result in personal

injury.

• UsetheHX-7B-WPorHX-7W-WPSpeakerSystem

in combination. Doing otherwise may cause the

speakertofalloff,resultinginpersonalinjury.

• Do not mount the speaker in locations exposed

to constant vibration. The rigging bracket can be

damagedbyexcessivevibration,potentiallycausing

the speakertofall, whichcouldresult in personal

injury.

• Avoidinstallingthespeakerinlocationsclosetothe

seashore or in indoor swimming facilities thatare

not well ventilated. In such locations, the bracket

maybevulnerabletocorrosion,eventuallyallowing

thespeakertofallresultinginpersonalinjury.

Indicatesapotentiallyhazardoussituationwhich,

ifmishandled,couldresultinmoderateorminor

personalinjury,and/orpropertydamage.

CAUTION

• Avoid touching the bracket's sharp metal edge to

preventinjury.

• Do not stand or sit on, nor hang down from the

bracketasthismaycausethespeakertofalldown

ordrop,resultinginpersonalinjuryand/orproperty

damage.

• Havethebracketcheckedperiodicallybytheshop

fromwhereitwaspurchased.Failuretodosomay

resultincorrosionordamagetothespeakerorits

riggingbracketthatcouldcausethespeakertofall,

possiblycausingpersonalinjury.

INSTALLATION MANUAL

SPEAkER RIGGING bRACkET HY-TM7b-WP

HY-TM7W-WP

ThankyouforpurchasingTOA’sSpeakerRiggingBracket.

Pleasecarefullyfollowtheinstructionsinthismanualtoensurelong,trouble-freeuseofyourequipment.

2. GENERAL DESCRIPTION

TheHY-TM7SeriesSpeakerRiggingBracketsareusedtohangtheHX-7B-WPorHX-7W-WPSpeakerSystem

directlyfromceilings,beamsorotherbuildingstructures,includingunderoutdooreaves.

3. NOTES ON INSTALLATION

• Observethefollowinginstructionswheninstallingthespeaker

system.

 Failuretodosocouldadverselyaffecttheirintendedweather-

resistantcapability,leadingtomalfunction.

· Installthespeakersysteminlocationsnotexposeddirectlyto

rain,suchasundereaves.

· Allspeakermodulesmustpointdownwardfromthehorizontal.

• Twojoined HX-7 Series SpeakerSystemscannot be installed

withthisbracket.

4. INSTALLATION

Step 1. Mountthisbrackettoaceiling,beam,etc.usingthebolts.

Boltsandnutsformountingthebracketontheceilingorbeamarenot

supplied.

Use bolts and nuts that are appropriate for the ceiling’s or beam’s

structureandcomposition.Failuretodosomaycausethespeakerto

fall,resultinginmaterialdamageandpossiblepersonalinjury.

WARNING

[Mounting dimensions]

(1.42")

146.5 (5.77")

[Front] [Right side]

ø8.5 (0.33") (with M8 weld nut)

ø8.5 (0.33")

(with M8 weld nut)

ø8.5 (0.33")

(with M8 weld nut)

ø8.5(0.33")

(6 positions)*

353 (13.9")

60 (2.36")

100 (3.94")100 (3.94")

(1.02")

(2.99")

126

(4.96")

291

(11.46")

220

(8.66")

170

(6.69")

φ8.5 (0.33")*

Note: Left-side surface same.

Unit: mm

*TheseholesnotttedwithM8weldnuts.

[Vertical installation]

Horizontal

Produkspesifikasjoner

Merke:	Toa
Kategori:	Ikke kategorisert
Modell:	HY-TM7B-WP
Vekt:	2500 g
Bredde:	433 mm
Dybde:	295 mm
Høyde:	57 mm
Materiale:	Rustfritt stål
Antall per pakke:	1 stykker
Kompatibilitet:	HX-7B-WP
Produktfarge:	Sort
Skruer inkludert:	Ja
