INSTRUCTION MANUAL

SIP VIDEO INTERCOM

Thank you for purchasing TOA’s SIP Video Intercom.

Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment.

SIP MULTIMEDIA STATION

SIP VIDEO DOOR STATION

SIP AUDIO DOOR STATION

4 SIZE BACK BOX

N-SP80MS1

N-SP80VS1

N-SP80AS1

YC-400

N-SP80 Series

N-SP80MS1

N-SP80VS1 N-SP80AS1

TABLE OF CONTENTS

1. SAFETY PRECAUTIONS

............................................................................. 4

2. GENERAL DESCRIPTION .......................................................................... 4

4. HANDLING PRECAUTIONS ...................................................................... 5

5. USAGE MODE .................................................................................................... 6

5.1. SIP Server Mode ................................................................................................... 6

5.2. Peer-to-Peer Mode ............................................................................................... 6

6. NOMENCLATURE AND FUNCTIONS ................................................. 7

6.1. N-SP80MS1 ........................................................................................................... 7

Front ...................................................................................................................... 7

Rear ...................................................................................................................... 8

Right side .............................................................................................................. 8

6.2. N-SP80VS1, N-SP80AS1 ...................................................................................... 9

Front ...................................................................................................................... 9

Rear ...................................................................................................................... 9

7. LIST OF SYSTEM FUNCTIONS ............................................................. 10

7.1. Basic Functions ................................................................................................... 10

8. SUMMARY OF THE PAGING FUNCTION ...................................... 12

8.1. Paging Configuration ........................................................................................... 12

8.2. Priority Setting of Paging and Conversation ....................................................... 12

MULTIMEDIA STATION'S FUNCTIONS AND OPERATIONS

... 13

9.1. Basic Usage ........................................................................................................ 13

9.2. Conversation's Functions and Operations .......................................................... 15

9.3. Paging Call Operation ......................................................................................... 23

9.4. Other Functions and Operations ......................................................................... 24

10. DOOR STATION'S FUNCTIONS AND OPERATIONS .......... 27

10.1 Functions for Conversations and Operations ..................................................... 27

10.2. Paging Function ................................................................................................ 27

10.3. Other Functions and Operations ....................................................................... 28

11. INSTALLATION ............................................................................................. 29

11.1. Safety Precautions for The Multimedia Station .................................................. 29

11.2 Installation of Door Station ................................................................................. 30

12. CONNECTION ................................................................................................ 31

12.1. N-SP80MS1 ....................................................................................................... 31

12.2. N-SP80VS1, N-SP80AS1 .................................................................................. 33

13. SYSTEM SETTING USING A WEB BROWSER ....................... 35

13.1. Before Performing System Setting .................................................................... 35

13.2. Confirming the IP Address of Each Device ....................................................... 35

13.3. N-SP80MS1 Setting .......................................................................................... 36

13.4. N-SP80VS1 and N-SP80AS1 Settings .............................................................. 55

Produkspesifikasjoner

Merke:	Toa
Kategori:	smarthjem
Modell:	N-SP80MS1
Vekt:	1400 g
Bredde:	240 mm
Dybde:	213 mm
Høyde:	120 mm
Berøringsskjerm:	Ja
Wi-Fi:	Ja
Wi-Fi-standarder:	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Innebygde høyttalere:	Ja
Innebygd mikrofon:	Ja
Materiale:	ABS
Antall per pakke:	1 stykker
Merkekompatibilitet:	TOA
Skjermoppløsning:	800 x 480 piksler
Produktfarge:	Sort
Skjermtype:	LCD
Skjermdiagonal:	7 "
Driftstemperatur (T-T):	0 - 40 °C
Ethernet LAN dataoverføringshastigheter:	10, 100 Mbit/s
Antall RJ45-porter:	2
Strøm over Ethernet (PoE):	Ja
DC inngående spenning:	12 V
